Filling machine manufacturing company and mineral water cup filling and sealing machine

Great Overall performance

Designed by our senior engineers who has rich experience in liquid semi-liquid powder areas, this machine has many newest technologies based on our advanced control system.

Smart Start System

With the efforts of our engineers, now we can start our machine easily Which means you will have no trouble to use when you get it.

Easy to Maintain

Don’t worry about machine maintain, we have optimize its structure, so now it is easy to maintain! Professional after sales service will be offered in its lifelong years!

Many Outputs

(100-20000cph)

Our SBG-60 series filling sealing

machine can offer many output.

You can choose freely!

Complete function

You can have the functions you need without

any problemsAdvanced pneumatic control system,

fill precisely and seal cups perfectly.

Accurate filling

No matter what kind of

materials can accurate

 cans,precisely fill without  splash,table and reliale.

Different type filling

SBG60 series filling sealing machine

can make different types foods , liquid,

semi-liquid,powder etc.

High-end materials

Mechanical parts are always our core advantages,

what make us stand out from competitors.

Electrical and pneumatic parts are all coming

from well-known companies

Elegant appearance

Alumite as moving moul-

ed extraordinary durable

and sanitary

Compare our other hot machines

Pictures

SBG-60

SBG-50

SBG-32

System

 Electrical and pneumatic system

Electrical

Output

1000-20000cph

700-3000 cph

700-2000cph

Lanes

2/4/6/8/10/12/14/16/20 lanes

1/2 lanes

1/2 lanes

Dimension

(3000-3500)*(600-800)*1600 mm

 1200*1200*1850mm

(1700-2200)*(540-560)*(1320-1400)

Weight

700-1000kg

350-450kg

260-360kg

Standard

functions

1. Cup falling

Pneumatic cylinder control

To suck the capsules down

Cylinder brand: AIRTAC

(Taiwan brand)

2. No material No filling

Sensors to check material. If no

material. Machine will not fill.

 Sensors are from AUTONICS

 from South Korea

3. Washing of cups

    function

To washing the cups before fill.

making the food become clean.

3. Filling material

Filling tank:10-20kgs around

 filling outlets

Ration type: Auger (high accuracy)

The filling volume can be adjusted from

 4 gramsto 15 grams.

4. Sealing

Sealing head are made of aluminum,

with the help of heaters.

Sealing temperature can be adjusted

between 0°-400°

5. Outputting

Pneumatic output: cups are being output

by pneumatic hands.

Equipped 50cm conveyor.

6. Date print

Print date on packaging

As this is a custom-build

machine, so each

machine’s functions

 will have some different.

Please confirm with our sales

before order.

Optional

functions

1. Glass covers(doors)

Use strong organic glass to protect

products from dust.

2. Safety sensors

To stop machines when open

the glass doors. To protect users’

safety

3. Air purify device

Can purify the air in the glass covers,

so the dust can be cleaned up!

4. Fealing sealing

machines

Can pack liquid semi-liquid powder

 etc. with nitrogen

 to keep fresh.

5. Nitrogen generator

If you don’t have it or cannot buy

Nitrogen locally,

can use our nitrogen generator,

which can offer

enough Nitrogen to keep food fresh

6. Preference brands

If you have any preference brands of the

electrical and pneumatic parts, you can

let us know.

7. Auger feeder

To load food automatically to the

 tank in the filling machine

If need other functions, just contact

 our sales!

Technical details of   Filling machine manufacturing company and mineral water cup filling and sealing machine

Model

SBG-60

Packing speed

1500-15000c/h

Voltage supply

380V/50Hz 1phase

Power

2-9.5 Kw

Cup loading holes on plate

2-12 holes

Air pressure

0.6-1.0 Mpa

Air consumption

0.65m3/min

Machine dimension

(3000-3500)*(600-800)*1600 mm

Packaging dimension

(3000-3500)*(600-800)*1600 mm+100mm

Net weight

700-1000 Kg

Gross weight

750-1050 Kg
