Dear Customer:
1. Have you passed the EIA (Environmental Impact Assessment) for recycling this resource?
2. Project Time Table.
3. Any regulations for recycling in your cuntry.
4. Wearhouse layout.
5. Local power supply.
6. Capacity demands.
7. Maximum size of the materials.
8. Any pictures helpful.
Basic information:
1, Equipment capacity : 15-20 pcs/hour
2, Dimensions: 35000*10000*7200mm
3, Equipment power: 176 Kw
4, Power supply: three-phase AC 380V/50Hz,
5, Nonferrous Recovery rate by weight>:≥90%
6,Ferrous Recovery rate by weight>: ≥ 95%
7, Plastic Recovery rate: ≥90%
8,PUR recovery rate by volume> : 90%
9,Noise, dust leaks and exhaust gas emissions in line with national standards and requirements
10, Equipment appearance and color: according to corporate standards.
Company introduction
Hunan VARY Tech.,Co.,Ltd
*Established in 2006,with registered captal CNY 65,000,000.00
*More than 1000 staffs, about 10% are technicians
* Listed on China stock exchange market
* Turnover reach 30 million USD
* 4 series recycling equipment & dozens of models. Annual production ability
* More than 500 sets More than 60% market share in China WEEE recycling industry
* More than 60% market share in China ELV Recycling Industry
2. Product Introduction
2.1 Work Flow
1.The first is to manually disassemble refrigerator cabinet and resulting plastic, wire, glass, circuit board. The
2.second is to reclaim refrigerant to ensure it would not pollute atmosphere.
3.The third is to dismantle compressor and condnser.
4.The fourth is to multi-level shred refrigerator body in shredder. In the shredder polyurethane is sucked out by air pump.
5.The fifth is to separate iron by permanent magnet.
6.In the last step aluminum and copper are separated by eddy current.
The entire processing Equipment is located in an enclosed workshop. Exhaust gas and dust can be discharged by high pressure positive blower after being processed by activated carbon adsorption and hop-pocket dust extraction.
Major components
Subsystems |
Function Description |
Pre-process System |
Including work station and refrigerant recycling. To manually disassemble compressor and other plastic components. |
Shredder |
Including fluid drive, constraint transport, belt transpot, and pulverizing device. To shred and transport materials. |
Urethane foam separator |
Original design of integrative device to shred efficiently and separate Urethane foam. |
Iron separator |
Including magnetic separator. To separate iron from processing material. |
Non-ferrous metal separator |
Including eddy current separator. To separate Non-ferrous metals from processing material |
Urethane foam secondary shredder and packing system |
Including Urethane foam shredder. To reduce gaps in foam for easy packing and transportation |
Safety System (optional) |
Including water spraying, nitrogen spraying and cyclopentane detection devices. To ensure safety of equipment. |
Exhaust Gas Process System (optional) |
Including activated carbon adsorption and hop-pocket dust extraction. To ensure emitted gas consist with national standard. |
Operation condition dynamic monitoring system |
Including screen monitoring and automatic control system. |
3. Input and Output
Input
Output
4. Product Overviews
VARY Certifications
