P20mm Full Color Outdoor Module Led Display

US$ 800 - 1,600 MOQ: 1 Square Meter

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

CCY

Model Number:

CCY-OF-P20

Shenzhen CreKing Electronics Technology Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name CCY

Model Number CCY-OF-P20

Usage Outdoor

Tube Chip Color Other, RGB

Display Function Animation

Pixels 20mm

Specifications

P20mm full color outdoor module led display
>High brightness
>energy saving
>Wide viewing angle
>Water-proof

P20mm full color outdoor module led display

>High brightness
>Low power&voltage
>Wide viewing angle
>Water-proof

advantages are:

We do the LED encapsulation by ourselves (Quality is under strict control, prices are very competitive).
We are professional and only concentrate on outdoor and indoor LED video displays.
Fast and punctual delivery. With full of advanced auto machines and well-trained workers, our delivery is always on time.
After-sales service. Our after-sales engineers have been in LED field for more than ten years who is sophisticated in programming all kinds of control systems, extending professional maintenance or repairing skills to customers.

Paremeters

Pixel Pitch	20 mm
Virtual pixel pitch	10mm
Density per sqm	2500 pixels
Pixel configuration	2R1G1B
LED package	DIP 546
Module resolution	16*8 dots
Module size	320mm*160mm
Cabinet size	1280mm*960 mm
Whiteness brightness	≥7500
Grey Scale/Color	Display colors≥16.7m
Best Viewing Distance	20m~140m
Driving method	static constant current
View Angle	(H) 110°~140°(V)/ 55°
Frame frequency	60 Hz
Refresh Rate	450 Hz ~ 4000Hz
Max power	750W/sqm
Average power	160W/sqm
Protection classification	IP65 front/IP54 rear
Weight	About 50 Kg/sqm
Install mode	Wall mount, hung anword stand structure
Cabinet Material	Iron/Aluminium
Working voltage	AC 110~220v/±10%
Control method	Synchronization
Malfunction dot rate	Leswors than 0.0001
Working temperature	-40~+60°C
Working Humidity	10~95%
Lifetime	100,000 hours (about 10 years)
MTBF	≥ 10000 hours
Whole display flatness	less than 1mm juncture
Transmission distance	LAN cable ≤ 100m, optic fiber transmission: MMF ≤500m, SMF ≤15km
