DEP105 4-20mA weighing indicator
- 1000 Set / Sets per Month
- Shenzhen
- T/T Credit Card
- laser distance meter PD38
- HANDHELD LASER DISTANCE METER,HANDHELD RANGE FINDER, DISTANCE METER,PD23,40M
- HANDHELD LASER DISTANCE METER,HANDHELD RANGE FINDER, DISTANCE METER,PD54,40M
- HANDHELD LASER DISTANCE METER,HANDHELD RANGE FINDER, DISTANCE METER,PD56,60M
- Laser Range Finder PD58
- laser distance meter HP800
Product Details
Place of Origin: | Hunan, China | Brand Name: | DETAIL | Model Number: | DEP105 |
Product Description
DEP105- weighing indicator
Model reference
MODEL | Weight indicate | 4 Point Relay | 0-10VDC/ 4-20MA output | Peak reserves | RS485/RS232 | Packing scale | Batching scale |
DEP105 | YES | NA | NA | YES | YES | NA | NA |
DEP105A | YES | NA | YES | YES | YES | NA | NA |
DEP105C | YES | YES | NA | NA | YES | NA | NA |
DEP105CA | YES | YES | YES | NA | YES | NA | NA |
DEP105P | YES | YES | YES | NA | YES | YES | NA |
DEP105B | YES | YES | YES | NA | YES | YES | YES |
Standard Function:
Input Signal | DC and DV signals of electrical resistance strain gage, weighing cell and proliferated silicon pressure sensor |
Display Mode | 5-bit 16mm high light LED display |
Comparing Control Output(option-able optional) | 4-point comparing output, 6 optional comparing modes, adjustable sensitivity of comparison value and comparing control output |
Analog Output(, optional) | 4mA – 20mA photoelectric isolation output of gross weight |
BCD Output(optional) | Parallel 29-bit non-isolated TTL level output or isolated OC output |
Communication Interface(optioanl) | Standard RS-485 and RS-232 interfaces, adjustable address and rate |
Display Output(optioanl) | 6-line differential transmission, adjustable frequency of transmission, distance of 1200m |
Digital Filtering | To filter high frequency small amplitude interference to ensure stability and accuracy of indication. |
Zero Tracking and Automatic Reset | Reading will be tracked until zero if weight is in the range of zero tracking and kept over 1 second. |
Change Detection | Reseting, shelling and tracking will not be executed until change of measured value in 1 second is beyond preset graduation value. |
Optional Output Control | Control power of comparing output and analog output can be granted to computers or meters after communication interfaces are determined. |
External Reset | Command of external reset is executed through on-off input. |
Printing Interface(option-able) | Manual and timing printing |
Price, Package and Service
1. Price : EXW, FOB, C&F
2. Payment: T/T in advance, PayPal, Western Union.
3. Packing : standard export packing, including instructions and certificate
4. Leading time : 3-7 working days according to order quantity
5. OEM available
6. Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder
7. 7 days free replace & 1 year free repair for quality warranty
FAQ
Q1:Can I have a sample for testing?
A: Yes, you can have samples from us.
The cost of samples will be higher than the cargo.
Q2:How can I get the after-service?
A:We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems,we also send the spare parts,but you should pay.
Q3:Do you have inspection procedures for all load cells?
A:100% self-inspection before packing.
I am Dita, thank you for visiting our website. Any inquiries, please contact us freely.
We will reply to you within 24 hours.
