LED beam moving head light is a mixture of red, green and blue to produce, via RGB electronic mixing, an endless palette of attractive pastel or deep colors, which has a multitude of benefits including silent operation, durability, long service life, high efficiency at electro-optic transfer, and low power consumption with compact size.
The LED wall washer uses DMX512 signal to control its colors and brightness. It is widely used at supermarket, Disco, shopping center, architectural building, hotel, garden and theater, etc.
Specification and Parameter
led beam moving head light
Technical DataModel |
Digital Moving Head Light M-2052 |
| Light Source | PHILIPS MSD 1200SA |
| Working Hour | 750 hours, Lamp holder G22 |
| Input Voltage |
Electric Ballast Version:00V/120V/200V/220V/230V/240V AC, 50/60HZ Magnetic Ballast Version: 220CAV, 50/60HZ, (200/230/240V AC, 50/60HZ available) |
| Power Consumption | Electric Ballast Version: 1500W@220V |
| Magnetic Ballast Version: 1600W@220V | |
| Color Wheel | CMY color mixing system with macro instruction function |
| 2 color wheels: with 6 replaceable colors plus white and half color, bi-direction rainbow effects available. | |
| Step / linear color diffusion selectable, Auto function, Sound Active function | |
| Color wheel Outside Dimension: 41.8mm | |
| CTC | 0~100% linear cooling system |
| Effect | side-by-side combination fresnel with angle adjustable |
| Soft Light / Frost: soft light 0~100% linear adjustment | |
| Zoom | DMX linear focusing |
| Beam Angle | 1°~87°linear adjustment |
| Strobe | dual-plate strobe, variable strobing 0.3~15 flash per sec, inside strobe macro-function |
| XY Movement Range | Pan 560°, Tilt 280°, Automatic Pan/Tilt correction, blackout movable |
| Control Channels | 17CH/32CH, channel order editable |
| Control Signal | DMX512, 3-Pin or 5-Pin XLR IN/OUT |
| Self-test Mode | self-test program editable |
| Pan, Tilt, CMY, and Dimmer speed adjustable | |
| LCD Display, displaying brightness adjustable (10-100%), working hour and bulb control mode selectable | |
| Ballast with auto energy saving, and transducer malfunction diagnosis system | |
| Housing | high intensity and heat resistant complex plastic |
| Protection Grade | IP20 |
| Dimension | 640mm×550mm×880mm |
| Net Weight | Electric Ballast Version: 39kg |
| Magnetic Ballast Version: 50kg | |
| Lamp work time | 750hrs |
| Color temperature | 6000K adjustable |
Item Pictures:
Features:
LED light series designed for professional stage and architectural lighting applications, it incorporates high power LED with 3 different basic colors: red, green and blue, it is easy to mix them into a color spectrum to create virtually unlimited selection of colors. With light source of LED, this fixture has following advantages:
1. Long service life, service life is 50000 hours under nominal working conditions, and only 5% decrease in the first 1000 working hours;
2. Bright colored, color saturation can be reached at more than 90% to produce more brilliant light effects;
3. High efficiency and low power consumption. There is no color filter loss, being efficient at electro-optic transfer;
4. RGB color mixing with or without DMX control;
5. Environmental protected, since there is no ultraviolet radiation and infrared ray in the spectrum, it is low at heat emission and radiation;
6. With a build-in stand alone function and master / slave mode available;
7. Current protection to PCB panel and over-heat protection;
8. 64 sub-ID codes addressing panel available in one DMX address.
With aluminum alloy housing, our LED light is of excellent quality and good durability. It is designed for both indoor and outdoor applications and typically used as a down light for stages or illumination of specific points of interest such a performer, status, buildings, and disco, etc. it is widely used at entertainment places, such as dancing hall, architectural building, discos, pubs, theaters, shows and clubs, etc.
Lighting effect & Successful case
CE certified:
LED Light Workshop
About MHG
Established in 2001, we are a professional manufacturer of stage lights and LED display, we have 6 product lines including LED Lights, Moving heads, cool lights, effect lights, color scrollors and special LED display plant, products are normally CE & Rohs certified.
And we are the member of China Entertainment Technology Association, of Seminar of China Television Broadcasting Institution, and of Society of China Illumination. Our ISO 9001 / 2008-certified factory has more than 200 workers and over 30 R&D staffs.
