Fiber Optic Amplifier FF-301
Features
Optical Fiber Sensor FF-301-16us, fastest response time Dual digital display:
• The fastest response time:16us;
• Longest detection range of up to 20m;
• Adjustable trigger delay time;
• Excellent anti-interference capability;
• Built-in adjustable timer;
• Digital display on the panel, you can adjust the display direction according to the direction of installation location;
• Connect up to 16 groups of FF-301-16us Sensor;
• Highlight surface can be detected;
• Dusty and humidity environment can still be stable;
• Different client, different choice
Specifications
Output Model |
NPN Single Output |
Fiber Amplifier Model |
FF-301-16us |
Operating Voltage |
12~24VDC |
Power Consumption |
Less than 45mA at 24V |
Short Circuit Protection |
Yes |
Working Indicator |
Red Led |
Digital Display |
4 bit green&4 bit red LCD Display |
Sensitivity Distance Setting |
Auto&Manual adjustment |
Response Time |
16us/70us/250us/2ms/8ms |
Timer Function |
ON Delay Time/OFF Delay timer, Adjustable valid or invalid (Regular time:1ms,5ms,10ms,20ms,40ms,100ms,500ms,1000ms) |
Timer Adjustable Time |
0.1ms~9s |
Input Setting Method |
Auto teach/test/sync |
Operating Temperature |
-25~55℃ |
Operating Humidity |
35~85% |
Storage Temperature |
-40~70℃ |
Storage Humidity |
35~85% |
Shockproof |
Frequency 10~150HZ double amplitude 0.75mm, XYZ direction each 2hours |
Waterproof Grade |
IP50 |
Material |
ABS/PC |
Weight |
65g |
Packaging & Shipping
Price, Package and Service
1. Price : EXW, FOB, C&F
2. Payment: T/T in advance, PayPal, Western Union.
3. Packing : standard export packing, including instructions and certificate
4. Leading time : 3-10 working days according to order quantity
5. OEM available
6. Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder
7. 1 year free repair for quality warranty
