Introduction
Model cm-JYB-K M is a cost efficient general purpose gage- only diffused Silicon pressure transmitter. Each unit is constructed of welded stainless steel for durability in dry rugged environments. Both gas and liquid pressure overloads of up to 50% over capacity are safely accepted. The transmitter uses our proprietary current output with digital compensation. This design references the primary pressure sensing diaphragm to the atmosphere, and provides a stable zero regardless of the transducer environment.
0.0015 % FS/°F temperature effect
0.2%, 0.5 % or 1.0% accuracy
0.35 to 100 Bar range
True gage or absolute
4 to 20 mA output / 0~5VDC output
Isolated double wall construction
Enhanced temperature stability
ROHS and CE Certification
Certified by: CE and ROHS.
Delivery time: 10-12 days after payment.
Payment by: L/C, T/T, Western Union, PAYPAL
We are professional manufacturer in the meters, we would like to offer you service on this field. we could make meters according your requests and your accuracy.
