First , summary
Armor it is can crooked for electric thermocouple not to have, able to bear high pressure, hot response time soon and a lot of advantages such as being sturdy and duable, it is regarded as the changer which measures temperature like detachable electric thermocouple , usually with showing the instrument , write down the instrument and electronic regulator and form a complete set and use, meanwhile, can also be regarded as the temperature sensing component of the detachable electric thermocouple . It can measure from the liquid in 0-800 degrees Centigrade of ranges in various kinds of production processes directly , steam , gas price quality and solid and superficial temperature.
Second , operation principle and basic structure
The operation principle containing electric thermocouple of the armour and basic characteristic are the same as ordinary electric thermocouple .
The principle of structure containing electric thermocouple of the armour is protected and managed by the conductor, high insulating magnesium oxidize overcoat 1Cr18Ni9Ti stainless steel, an organic whole of numerous Israel was drawn and made .
Armor terminal box have simple and easy type, waterproof type, handle type, little wiring boxlike, connect person who insert , compensate wire many kinds of structure pattern at present.
Third, main technical parameter
1.Measure the range and permit difference
Note: (1)Diameter 3mm is insulating type the total length L of electric thermocouple name of armor can't be greater than 10000mm.
(2)Must consult ordering with our company in 2mm armor electric thermocouple of the diameter.
Features
- Wetted Part: SUS304, TEFLON.
- Operating Temp: -30°C~150°C.
- Contact Rating: 30W / 200 Vdc.
- Mounting Screw : 1" PT.
- Enclosure Protection: SF1800: IP-65.
SF1710: EExd II C T6. - Suitable Pipe: 1"~3".
- Operating Pressure: 355 PSI.
- Detection: Reversible.
Certified by: CE and ROHS.
Delivery time: 10-12 days after payment.
Payment by: L/C, T/T, Western Union, PAYPAL
We are professional manufacturer in the meters, we would like to offer you service on this field. we could make meters according your requests and your accuracy.
