Specifications
DMX512 lighting controllerfor 40 units with a max.
36 channels each
Model: PILOT 2000
Technical Parameters: Universal DMX controller for 40 units with a maximum of 36 channels each.
Constant monitoring of output parameters due to a large back-lit display.
Using the Scroll function, operators can control blocks of 6 channels at a time.
With the (editable) internal libraries, it's possible to assign functions to the faders at will: physical and logic channels are independent.
40 chases - Programs - Presets - Psychos.
The section dedicated to scanners and moving head fixtures has a twin co-ordinate system: absolute and relative. This ensures perfect fixture positioning.
Pilot 2000 can be mounted in a standard 19" rack (5 units), but can also be used as a desk-top unit.
DMX in/out connector, SMPTE socket for changing memories in sync, independent regulation of scene and preset crossfade times.
Audio input and built-in microphone for music sync functions.
MIDI in/thru/out connector. Data and memories can be downloaded to a PC.
Jack socket for pedal for stepping up/down through memories.
Universal AL4 switching power supply included.
Dimension: 750mm×482mm×222mm
