Specifications
Multi-function LED Lights for TV Studio;108Pcs*3W LEDs Soft Lighting;
60 * 120 reflector , soft light board;
good design
108Pcs*3W LEDs photo and television Multi-function LED Lights for TV Studio
M-L324PR-RGB/RGBW Multi-function LED studio lighting is a kind of multi-function LED light , adopts cool light source, is widely used for conference hall, studio, and multifunctional hall, etc.
- Fan cool light, suitable for indoor stage, KTV, bar, exhibition, club, meeting hall, shopping mall, indoor square, parking place etc.
- 60 * 120° reflector + soft light board: to make largest view angle of the light, very soft light output
- High power : good design for cooling , LED best performance.
- Best linear dimming: adjust color and brightness without jumping and the flicker, perform smooth transition, this is not available in tranditional lights.
- According to the LED actual temperature regulating output power: the maximum protection and keep safe useing of LED lights
Specification and Parameter
| Technical DataModel | LED Digital Soft Panel Light M-L324PR-RGBW | LED Digital Soft Panel Light M-L324PR-RGB |
| Power Supply | 100-240AC/50/60HZ | |
| Power Consumption | 408W Max | |
| Light Source | 108Pcs high power 3W LEDs Red:27pcs*3w;Green:27pcs*3w;Blue:27pcs*3w; White:27pcs*3w |
108Pcs high power 3W LEDs Red:36pcs*3w;Green:36pcs*3w;Blue:36pcs*3w |
| Dimmer | 0~ 100% linear adjustable | |
| Strobe | 1~20 Hz | |
| Beam Angle | 90° | |
| Control Signal | DMX512,Auto Mode | |
| Control Channels | 10 | |
| Input signal | XLR 3-pin(In & OUT) | |
| Case Material | Aluminium Blander (Optional) | |
| Protection Grade | IP22 | |
| Working temperature | -20°C~ 40°C | |
| Net Weight | 11.8KG | |
| Dimension | 583×394×117mm | |
| Application | stage, studio, multi-function hall. | |
Item Pictures:
Lighting effect
LED Light Workshop
Established in 2001, we are a professional manufacturer of stage lights and LED display, we have 6 product lines including LED Lights, Moving heads, cool lights, effect lights, color scrollors and special LED display plant, products are normally CE & Rohs certified.
And we are the member of China Entertainment Technology Association, of Seminar of China Television Broadcasting Institution, and of Society of China Illumination. Our ISO 9001 / 2008-certified factory has more than 200 workers and over 30 R&D staffs.
