Wifi Adapter for Hdmi

Negotiable MOQ: 500 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ASK

Model Number:

HDCN0010M1

Shenzhen ASK Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen/hongkong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ASK

Model Number HDCN0010M1

Specifications

Wifi adapter for hdmi
Wifi to hdmi or vga output
Support to 1080P

FEATURES:

Supports one HDMI output and one VGA output, the ports can automatically detect the display device and switch

HD resolution up to 1920x1080_30/60p (some TV may not support 60P because it is incompatible with the device)

Support a 3.5mm stereo headphone audio output

Wirelessly send Audio and Video from your PC/Mobile phone to an HDTV

Supports USB/LAN mirror or video extension of your PC content on your HDMI display

Supports DLNA/Miracast connection, easy to share the wonderful contents in PC/Mobile phone

Supports MicroSD card/ flash disk/ local disk (2GB), can play video/music/photo and office document etc.

when connecting to USB device port of your PC via USB cable, can be used as a card reader

Support wireless router

Support multiple operating system, e.g. Win XP, Win7, Win Vista, Android, iOS, Mac OS etc.

USB host interface can provide high current (1A) charging

Multi language menu

DC5V/2A power adapter

SPECIFICATIONS: HDCN0010M1

VGA output resolution	up to 1920x1080 @60Hz
HDMI output resolution	up to 1080P/30Hz
HDMI audio format	DTS-HD/Dolby-true HD/LPCM/DTS/Dolby-AC3/DSD
Wireless Frequency range	2.4~2.4835GHz
Wireless transmission rate	300Mbps
Wireless transmit power	18dBm (MAX EIRP)
Transmission distance	15m (Indoor and no obstacle)
Transmission delay	≤200ms(Related to PC performance,may be greater than this value)
HDMI output cable distance	≤20m AWG26 HDMI standard cablepan>may be greater than this value)
VGA output cable distance	≤15m VGA standard cable
Max working current	400mA
Power adapter format Input	AC 100V~240V 50HZ/60HZ; DC5V/2A
Operating Temperature range	.0 to +40°C
Storage Temperature range	20 to +60°C
Operating Humidity range	10 to 90%RH (No Condensation)
Case size (L x W x H)	102x66x25 (mm)
Weight	90g
