<h2>sdi splitter 1x4 support four sdi out</h2>
| Feature |
One Signal distribute to four SDI signal out. Support SD-SDI, HD-SDI and 3G-SDI Video Format. SDI Supports1080P/1080I/720P/576I/ 480I Video Resolution. Support SDI transmission Speed: SD-SDI:270MbPs,HD-SDI:1.485GbPs and 3G-SDI: 2.97GbPs. Supported Max Cable Length(SYV-75-5):SD supports up to 400m,HD supports up to 200m, 3G supports up to 80~100m(Note: The cable length will depend on the cable spec) Support deep color 8bit, 10bit, 12bit Support up to 3G-SDI Audio and Video Output Simultaneously Support Clock Recovery No Any Drive Need, Support Hot-Plug, Plug and Play Wide voltage input, It can support DC 5V~ 12V input
|
| Specification |
Support SDI Format....................SD-SDI,HD-SDI and 3G-SDI SDI resolution............................ 1080P/1080I/720P/576I/ 480I Support video color format ........................8bit/deep color 10bit,12bit Audio Signal.............................. SDI Built-in SDI baud rate......................270Mbps,1.485Gbps and 2.97Gbps Coaxial cable Characteristic impedance......................75Ω Max working current..............................300mA/DC 5V Power adapter format.....Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V~12V/2A Operating Temperature range......................... -10 to +55℃ Storage Temperature range....................... -20 to +60℃ Operating Humidity range..................10 to 90%RH (No Condensation) Storage Humidity range....................5 to 95%RH (No Condensation) Dimension (L x W x H) ............... .......... 178X66X28 (mm) Weight................................... .....418g |
hdmi to sdi scaler converter sdi to hdmi converter with extend
sdi splitter 1x2 support 100m sdi splitter 1x4 support four sdi
sdi to analog converter
Standard Package: Blister Box+ Instruction book + white box .Mostly,we could provide our Ai. diecut for customer to add their own design.Or We could also do customized package as customer's requirements.
sdi splitter 1x4 support four sdi out
Business Terms
| Accepted Delivery Terms: | FOB, CIF, EXW |
| Accepted Payment Currency: | USD, EUR, HKD, GBP, CNY |
| Accepted Payment Type: | T/T, L/C, Western Union, Cash |
| Nearest Port: | Shenzhen |
Company Profile
We arethe earliest developers and manufacturers committed to HDMI audio and video application system in China since 2004 with holding 20 patents.
By service our customers all over the world, we have consisted a super strong R&D team make up by 30 engineers which most with 6-10 years experience in HDMI and HDMI accessories products. Backed with vast experiences in design, engineering, manufacturing, we have build long term business with Samsung, Song, LG, Skyworth, TCL and Hair. We are not just manufactory for HDMI products, we are also provide HDMI application resolution for customer.
Factory Capacity
We strictly adhere to ISO 9001:2008 standards since we set up the factory by 2004. Also we are the holder for the certificate of ISO ,HDMI ATC, USB, UL, ROHS, CE, FCC and EMC. By implement the above high quality and technology standard, we are confident to make promise to every of our customer that all of our products is 3 years quality guarantee.
The published products are included HDMI splitters, switchers, converters, true matrixes, HDMI extenders and smart safe system products, but we are keeping publishi new product every month.
sdi splitter 1x4 support four sdi out
1. About sample: Sample can be ready with 5 days, for customized sample lead time is 20 days.
2. Payment service: T/T,30% deposit,70% before the dilivery.
3. After-sale service: We offered with 3 years quality guarantee.
4. Response service: We will reply you within about 24 hours.
5. Customize service: OEM and ODM.
A.How long about the samples ?
A1:About 3-5 days.
B.How long can be ready about the goods ?
B1:It usually takes about 30 working days,it is based on the detailed QTY.
C.Can you offer the OEM and ODM service ?
C1:Yes,of course,as we have our own design team.
D.What is the type of your company ?
D1:We are the earliest developers and manufacturers committed to HDMI audio and video application system in China since 2004 with holding 20 patents. We are also offered with product solution.
