Home > Electrical & Electronics > Passive Components > Capacitor > Wholesale New HDMI Surge Protector

Wholesale New HDMI Surge Protector

Negotiable MOQ: 50 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

ASK

Model Number:

HDEX001M1

Contact Supplier Request Quote Chat Now

Shenzhen ASK Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name ASK

Model Number HDEX001M1

Specifications

Designed for protect the HDMI device that against with the static discharge, lighting surge, electrical fast transient burst.

Features:

1. Protect HDMI input and output for ESD and Lightning Surge.
2. Meet IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact).
3. Meet IEC 61000-4-4 (EFT) 40A (5/50ns).
4. Meet IEC 61000-4-5 (Lightning) 5A (8/20µs).
5. Support HDMI 1.4 with 3D,4KX2K and HEAC.
6. Solid-state silicon-avalanche technology.
7. Support HDCP.
8. No loss of quality.
9. nstalls in minutes.
10. No Need Power Adptor.

specifications:

HDMI version…………………………………… HDMI 1.4 with 3D ,4Kx2K,HEAC
HDMI resolution …………………………...........24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support video color format …………………….24bit/deep color 30bit,36bit, 48bit
Support audio format……...................................DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HD(HBR)
Max bandwidth…………………………………...340MHz
Max baud rate……………………........................10.2Gbps
Input/Output TMDS signal ...................................0.5~1.5Volts p-p(TTL)
Input/Output DDC signal ……………………….5Volts p-p (TTL)
Max working current…………………………......50mA
Operating Temperature range……................... (-15 to +55°C)
Operating Humidity range....................................5 to 90%RH (No Condensation)
Dimension (L x W x H) ………………………….43.5x64x16.5 (mm)
Weight…..................................................................40g

The accessories with the machines:

1. One HDMI Surge Protector       1PCS
2. One pc of Manual                       1PCS
3. One Ground Wire                     1PCS
4. Ground Screw                             2 PCS
