Specifications
HDMI Extender by Double CAT6/7 up to 60m, full hd 1080p, 3D supportedhdbaset hdmi extender up to 60M by Double Cat6/7 Cable
HDMI Extender over double cat6/7(RJ45) 60M, 1080P full HD supported
1. Support HDMI 1.3 protocol
2. HDCP 1.2 protocol compliant
3. Support video input: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
4. Signal tranmission: Double cat-5e or cat-6(recommended) cables up to 60 metres instead
of HDMI calbes are connected between TX and RX Extender.
5. Support video output: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
6. Support CEC
7. Audio format support: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
8. LED indication: when power is supplied or device is working, LED relative to is light.
9. Support up to 20metres AWG26 cable length between extender and source & sink device
10. No loss of quality
11. Installs in minutes
12. Need DC5V/2A power supply
Specification:
Length of CAT-6 cable between Rx and TX..............................Up to 60 metres
HDMI Input........................24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support audio format input...DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
HDMI Output.....................24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support audio format output...............................LPCM7.1/DTS/Dolby-AC3/DSD
Max bandwidth.................................................................................165MHz
Max baud rate...............................................................................4.95Gbps
Input Video signal ...............................................................0.5~1.5Volts p-p
Output DDC signal .............................................................5Volts p-p (TT1L)
Input/Output HDMI1.3 cable distance.....≤20m AWG26 HDMI 1.3 standard cable
Max working current..........................................................................800mA
Power adapter format.....Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/2A
Operating Temperature range.................................................(-15 to +55°C)
Operating Humidity range................................5 to 90%RH (No Condensation)
Dimension (L x W x H) .........................................................82x44x22 (mm)
Weight..............................................................................................200g
HDMI Extender over double cat6/7(RJ45) 60M, 1080P full HD supported
