Specifications
The Extender use double cat-6 cables up to 30 meters instead of HDMI cable to transmit high definition signal up to 30M.
Features:
1. Support video input : 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i.
2. Signal transmission : To use double cat-5e or cat-6(recommended) cables up to 30 meters instead of using the HDMI cables connect the transmitter and the receiver of the Extender.
3. Support video output : 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i.
4. Support CEC.
5. Audio format support : DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD.
6. Support IR extender function (optional).
7. LED indication: when power is supplied or device is working, the related light will go bright.
8. Support up to 30 meters AWG26 cable length between extender and source & sink device.
9. No loss of quality.
10.Installs in minutes.
11.Need DC5V/1A power supply.
Specifications:
Length of CAT-6 cable between Rx and TX…..……………….……………..Up to 30 meters
HDMI Input…..…………………...………24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support audio format input..………DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
HDMI Output…..…………….…...………24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support audio format output...……. …………………………LPCM7.1/DTS/Dolby-AC3/DSD
Max bandwidth……………………………………………………………………………165MHz
Max baud rate……………….…….………………….………….………………………4.95Gbps
Input Video signal ………….…………………………..…………………….… 0.5~1.5Volts p-p
Output DDC signal …………………………………………………………… 5Volts p-p (TT1L)
Input/Output HDMI cable distance………….……………..≤15AWG26 HDMI standard cable
Max working current………………………………………………………………………...200mA
Power adapter format………..…Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/500mA
Operating Temperature range……..…………….………………………………… (-15 to +55°C)
Operating Humidity range………………………….….……….5 to 90%RH (No Condensation)
Dimension (L x W x H) ……………………………….…………………………82x44x22 (mm)
Weight…..………………………………………………………..………………………………200g
The accessories with the machines:
1, 5V Power Adaptor
2, one pc of Manual
3, IR receiver unit (optional)
4, IR transmitter unit (optional)
5, IR interface adapter (optional)
