Home > Consumer Electronics > Audio & Sets > Home Theatre System > 3D CAT5 CAT6 100m HDMI Extender by Signal Cat

3D CAT5 CAT6 100m HDMI Extender by Signal Cat

Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

ASK

Model Number:

HDT001

Place of Origin:

China

Contact Supplier Request Quote Chat Now

Shenzhen ASK Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name ASK

Model Number HDT001

Place of Origin China

Specifications

HDMI extender by signal CAT5/6 up to 100M, when one of the extra four Ethernet Port connect to internet, the rest can connect PC

Features:

1. Support 3D
2. Support HDCP
3. Video Input Support: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
4. Support 1080p@60Hz@48bit pixels
5. Through one cat5e or cat6 to send the 10.2Gbps HDMI Signal and 100Mbps Ethernet signal,the distance can reach 100m.
6. There are four standard Ethernet port on the sender and receiver. While use one Ethernet signal to connect any of the four Ethernet port in sender and receiver Any of the four Ethernet port in sender and receiver, the other three Ethernet port can go connection with pc to surf
7. Video Out Support: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
8. Support CEC
9. Support Audio Format: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
10.IR Extension Function, you can use the Signal source remote to control the source device at the receiver
11.Led Status Light:When the power or extender is working, the related led light will go bright
12.Use standard HDMI Cable and Ethernet Cable
13.No loss of Signal
14.Easy Operation and Installation
15.With 5V/2A Power Adaptor

Specifications:

Length of CAT-6 cable between Rx and TX	Up to 100 meters
HDMI Input	24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support audio format input	DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
HDMI Output	24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support audio format output	LPCM7.1/DTS/Dolby-AC3/DSD
Max bandwidth	334MHz
Max baud rate	10.2Gbps
Input Video signal	0.5~1.5Volts p-p
Output DDC signal	5Volts p-p (TT1L)
Input/Output HDMI cable distance	≤20m AWG26 HDMI standard cable
Max working current	1000mA
Power adapter format	Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/2A
Operating Temperature range	(-15 to +55°C)
Operating Humidity range	5 to 90%RH (No Condensation)
Dimension (L x W x H)	115x78x22(mm)(RX/TX)
Weight	200g
