Wireless Hdmi Transmitter and Receiver With IR Control 30M

Wireless Hdmi Transmitter and Receiver With IR Control 30M thumbnail-1
Wireless Hdmi Transmitter and Receiver With IR Control 30M photo-1
Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
ASK
Model Number:
HDE004
Place of Origin:
China
Contact Supplier Request Quote Chat Now
Shenzhen ASK Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen / HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name ASK
Model Number HDE004
Place of Origin China

Specifications

Transmission range up to 30M.
Support EDID and CEC function.
HDMI v1.3, support HDCP1.2 protocols and WHDI 1.0 specification.



Features:



1.Instant wireless HD AV transmission;
2.Transmission range in the vacancy indoor environment 30m;
3.Supporting the video HDMI interface at the maximum of 1080P60 Hz;
4.Supporting HDMI1.3 and HDCP1.2 protocols;
5.Supporting the EDID function;
6.Supporting the CEC function (for the receiving and display devices);
7.Supporting the IR extension transmission function;
8.Transmission power 12 dBm;
9.Supporting the point-to-point transmission function currently
10.which can be expanded to the point to multi-point or multi-pointto multi-point transmission function;
11.Supporting the AES128-bit image encryption Function;
12.Supporting the reverse back-transmission channel at the maximum rate of 100 kbs;
13.Supporting OSD display;
14.Supporting WHDI 1.0 specification.





Technical Specifications:





Video formats supported

TV 1080p, 1080i, 720p, 576p,480p

PC: VGA(640X480), SVGA(800X600),
XGA(1024X768), SXGA(1280X1024)
Audio formats supported PCM,DTS, DOCBY DIGITAL
RF communication system MIMO
Modulation mode OFDM
Maximum transmission power Maximum transmission power

12dBm
Image transmission distance ≥30m
Image delay <1 ms

Transmission/receiving  antenna mode

 Built-in
Operating frequency 5.1~5.9GHz

IR carrier modulation frequency supporte

 38KHz
Operating power supply 100-240V AC mains, 5V 2A DC power
Storage temperature -20~80OC
Storage temperature -10~50 C





Specifications:





Items

HDE004

Transmitter

Transmission Frequency

5.1~5.9GHz

Frequency Stability

±4PPM

Bandwidth

40MHz

Transmission Power

≥12dBm

Receiving Sensitivity

≤-75dBm

System Latency

≤1ms

Sending/receiving channel

4 channels for sending/1channel for receiving

HD video protocol

HDMI 1.3

HD video encryption protocol

HDCP 1.2

Unobstructed Effective Range

≥30m

Power Supply

5VDC

Consumption Current

2A 10%

Dimensions (W x D x H)

148 x 97 x 18 (mm)

Approx. Weight

440g (including the base)

Receiver

Receiving Frequency

5.1~5.9GHz

RF communication system

MIMO

Modulation mode

OFDM

Frequency stability

±4PPM

Bandwidth

40MHz

Transmission Power

≥15dBm

Receiving Sensitivit

≤-65dBm

System latency

≤1ms

Sending/receiving channel

1channel for sending/4 channels for receiving

HD video protocol

HDMI 1.3

HD video encryption protocol

HDCP 1.2

Unobstructed Effective Range

≥30m

Power Supply

5VDC

Consumption Current

2A±10%

Dimensions (W x D x H)

148 x 97 x 18 (mm)

Approx. Weight

436g (including the base)



Operating Temperature

-10 C~50 C

Storage Temperature

-20 C~80 C

Operating Humidity

15~85%RH





Wireless hdmi transmitter and receiver with IR control 30MWireless hdmi transmitter and receiver with IR control 30MWireless hdmi transmitter and receiver with IR control 30M





Wireless hdmi transmitter and receiver with IR control 30M
