Specifications
HDMI ESD Surge Portector for PS3/ XBOX/TV1: hdmi ESD Surge ,EFT, Lightning protector
2: ESD surge protect ps3,xbox,ps3,tv,DVD
ESD Surge Protector--Protection Against ESD / Power Surge / Lightning
Features:
1. Protect HDMI input and output for ESD and Lightning Surge
2. Meet IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact).
3. Meet IEC 61000-4-4 (EFT) 40A (5/50ns).
4. Meet IEC 61000-4-5 (Lightning) 5A (8/20µs).
5. Support HDMI 1.4 with 3D,4KX2K and HEAC.
6. Solid-state silicon-avalanche technology.
7. Support HDCP
8. No loss of quality
9. nstalls in minutes
10. No Need Power Adptor
specifications:
HDMI version…………………………………… HDMI 1.4 with 3D ,4Kx2K,HEAC
HDMI resolution …………………………...........24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support video color format …………………….24bit/deep color 30bit,36bit, 48bit
Support audio format……...................................DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HD(HBR)
Max bandwidth…………………………………...340MHz
Max baud rate……………………........................10.2Gbps
Input/Output TMDS signal ...................................0.5~1.5Volts p-p(TTL)
Input/Output DDC signal ……………………….5Volts p-p (TTL)
Max working current…………………………......50mA
Operating Temperature range……................... (-15 to +55°C)
Operating Humidity range....................................5 to 90%RH (No Condensation)
Dimension (L x W x H) ………………………….43.5x64x16.5 (mm)
Weight…..................................................................40g
The accessories with the machines:
1. One HDMI Surge Protector 1PCS
2. One pc of Manual 1PCS
3. One Ground Wire 1PCS
4. Ground Screw 2 PCS
ESD Surge Protector--Protection Against ESD / Power Surge / Lightning
