HDMI Surge Protector for Home TheatreUS$ 1 - 15MOQ: 1 Piece -
HDMI EFT Lightning Protector for XBOX 360/ PS3/DVDUS$ 10 - 13MOQ: 10 Sets
-
High Quality HDMI ESD Surge Protector for XBOX 360US$ 10 - 13MOQ: 10 Sets
-
Wholesaler HDMI Surge Portector for PS3/ XBOX/ TVUS$ 10 - 13MOQ: 10 Sets
-
ESD Surge Protector--Protection Against ESD / Power Surge / LightningUS$ 10 - 13MOQ: 10 Sets
Specifications:
HDMI version………………………………………………….. HDMI 1.4 with 3D ,4Kx2K,HEAC
HDMI resolution …………………………....24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support video color format ……………………...….….……..24bit/deep color 30bit,36bit, 48bit
Support audio format……..DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HD(HBR)
Max bandwidth………………………………………………..….………………………….340MHz
Max baudrate…………………….………………….……………………………………..10.2Gbps
Input/Output TMDS signal ………….………………………..………... …..0.5~1.5Volts p-p(TTL)
Input/Output DDC signal …………………………………………..……...……… 5Volts p-p (TTL)
Max working current………………………………..……………………………………….....50mA
Operating Temperature range……..…………….………………………………… (-15 to +55℃)
Operating Humidity range………………………….….………..5 to 90%RH (No Condensation)
Dimension (L x W x H) ……………………………….………………...……43.5x64x16.5 (mm)
Weight…..………………………………………………………..…….…………………..………40g
FEATURES
lProtect HDMI input and output for ESD and Lightning Surge
lMeet IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact).
lMeet IEC 61000-4-4 (EFT) 40A (5/50ns).
lMeet IEC 61000-4-5 (Lightning) 5A (8/20µs).
lSupport HDMI 1.4 with 3D,4KX2K and HEAC.
lSolid-state silicon-avalanche technology.
lSupport HDCP
lNo loss of quality
lInstalls in minutes
