2 Nozzles Filling Machine FM-SDV

2 Nozzles Filling Machine FM-SDV photo-1
2 Nozzles Filling Machine FM-SDV photo-2
2 Nozzles Filling Machine FM-SDV photo-3
2 Nozzles Filling Machine FM-SDV photo-4
2 Nozzles Filling Machine FM-SDV photo-5
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Beverage, Commodity, Medical, Chemical, Other, Food, Beverage, Commodity, Medical, Chemical, liquid filling
Packaging Type:
Cans, Bottles, Barrel, Pouch
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Food, Beverage, Commodity, Medical, Chemical, Other, Food, Beverage, Commodity, Medical, Chemical, liquid filling
Packaging Type Cans, Bottles, Barrel, Pouch
Packaging Material Plastic, Metal, Glass
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage 220V/110V
Power 50HZ
Place of Origin Shanghai, China
Brand Name CrossQ
Model Number FM-SLV
Certification CE

Specifications

2 Heads Liquid Filling Machine
Model: FM-SDV
Type: platform & piston type

Semi-auto Volume Type Filling Machine for Liquid FM-SDV

(Double Filling Nozzles)

2 Nozzles Filling Machine FM-SDV

[FEATURE]

1. This machine is belonged to semi-automatic piston type filling machine for liquid.

2. Filling quantity and speed can be adjusted..
3. Easy to operate, with high accuracy, simple to maintain and clean.
4. Pneumatic parts: normally adopt Airtac brand, also can choose FESTO,
5. Can set manual or automatic mode.
6. With good structure, easy to removal & installation.

7. Material contact part with SUS304 (SUS316 be optional), meet GMP operational standard.

8. With excellent design, with vertical and small structure to save installation space.

9. Be suitable for various products with small weight.

10. Seal parts with silicone rubber which with high anti-abrasion, anti-heat, anti-acid,

anti-corrosion function, with fluorine rubber which is high anti-abrasion, anti-resistance, anti-acid, and anti-corrosive.





[APPLICATION]

FM-SDV mainly used for filling liquid, such as lotion, care solution liquid, shampoo, wash clean, lubricants, oil etc.



[SPECIFICATION]

Type: FM-SDV/5000

Filling Range:500-5000ml
Filling Accuracy:±0.5%
Filling Speed:8-30pcs/min
Power Supply: AC220V 50HZ
Air Supply: 800L/min
Net Weight: 180KG
Size:1000*800*1750(L*W*H) (mm)



[SERIES]

Type

Name

Filling Range

Filling Speed

Air Supply

Power

Supply

Dimension (mm)

Weight

FM-SDV/5000

Double Nozzle Filler



1000-5000ml

10-30pcs/min

400L/min



AC220V 50HZ

1000x800x1750

180kg

FM-SDV/1000

500-1000ml

30-50pcs/min

300L/min

1000x800x1750

160kg

FM-SDV/500

100-500ml

40-60pcs/min

200L/min

1000x800x1750

140kg
