Liquid Filling Machine FM-SLV
- 50 Set / Sets per Month
- Shanghai Port China
- T/T
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Other, liquid filling | Packaging Type: | Bottles |
Packaging Material: | Glass | Automatic Grade: | Semi-Automatic | Driven Type: | Electric |
Voltage: | 220V/110V | Power: | 50HZ | Place of Origin: | Shanghai, China |
Brand Name: | CrossQ | Model Number: | FM-SLV |
Product Description
Liquid Filling Machine
Model : FM-SLV
-Vertical Type
FEATURES
1. This machine is belonged to semi-automatic piston type filling machine for liquid.
2. Filling quantity and speed can be adjusted..
3. Easy to operate, with high accuracy, simple to maintain and clean.
4. Pneumatic parts: normally adopt Airtac brand, also can choose FESTO,
5. Can set manual or automatic mode.
6. With good structure, easy to removal & installation.
7. Material contact part with SUS316, meet GMP operational standard.
8. With excellent design, with vertical and small structure to save installation space.
9. Be suitable for various products with small weight.
10. Seal parts with silicone rubber which with high anti-abrasion, anti-heat, anti-acid,
anti-corrosion function, with fluorine rubber which is high anti-abrasion, anti-resistance, anti-acid, and anti-corrosive.
APPLICATION
FM-SLV mainly used for filling liquid, such as lotion, care solution liquid, shampoo, wash clean,
lubricants, oil etc.
SERIES
Type | Filling Range | Filling Speed | Air supply | Power Supply | Dimension(mm) | Weight |
FM-SLV/100 | 10-100ml | 10-40pcs/min | 100L/min | AC220V 50HZ | 980x500x1200 | 35kg |
FM-SLV/250 | 30-250ml | 10-40pcs/min | 120L/min | AC220V 50HZ | 1000x550x1250 | 38kg |
FM-SLV/500 | 100-500ml | 10-30pcs/min | 210L/min | AC220V 50HZ | 1100x550x1300 | 40kg |
FM-SLV/1000 | 200-1000ml | 10-25pcs/min | 315L/min | AC220V 50HZ | 1300x700x1350 | 45kg |
FM-SLV/2000 | 500-2000ml | 5-15pcs/min | 405L/min | AC220V 50HZ | 1650x700x1200 | 55kg |
FM-SLV/5000 | 1000-5000ml | 5-15pcs/min | 450L/min | AC220V 50HZ | 1700x750x1400 | 78kg |
