Home > Products > STEEL WIRE REINFORCED POLYETHYLENE PIPE > China high quality steel mesh wire reinforced hose pipe manufacturer
China high quality steel mesh wire reinforced hose pipe manufacturer
- 100000 Meter / Meters per Month
- Qingdao Tianjin Shanghai
- T/T Credit Card
Product Details
Place of Origin: | Henan, China | Brand Name: | Max | Model Number: | Steel Wire Reinforced PE Pipe |
Material: | PE | Specification: | DN50MM-DN1000MM | Length: | 6m, 12m or as required |
Thickness: | 4.5mm-40mm | Standard: | CJ/T189-2007 |
Product Description
HDPE pipe for water supply
HDPE pipe for gas supply
HDPE pipe for mining use
HDPE pipe for drainage
HDPE PIPE feature
1.Nontoxic:
PE pipe material nontoxic, tasteless,it belongs to green building materials, never scaling,
which can effectively improve the water quality.
2.Corrosion resistance:
High resistance to attack from various types of chemicals. No electrochemical corrosion.
3.No Leakage:
PE pipe is connected in the ways of butt fusion, socket fusion and electrofusion and the
strength of joint point is higher than tube itself .
4.higher flow capacity:
The Smooth inner wall is easy for pipeline transportation .Under the same condition
delivery capacity can be increased by 30%.
5.Convenient for construction and installation:
PE pipe could be installed in a variety of trenchless ways, so it is very convenient for
construction and installation.
6.Lower system and maintenance costs:
PE pipe is not only convenient to transport and install, but also reduce the worker’s
labor intensity and improve work efficiency.
7.Longevity:
50 years under pressure use.
8. Recycled and Environment-friendly
2.Advantage of hdpe pipe
1.anti-scaling
ld stability
3.smooth interior
4.zero leak rate
5.high performance
6.weather resistance
rrosion resistance
8.light weight and weldability
9.Non-toxic ,tasteless, odourless
3. Application of hdpe pipe
(1). Municipal/Industrial Market: Underground Potable Water Distribution
(2). Drainage: Storm Water, Culverts, Highway /Residential / Agricultural Water Collection
(3). Sanitary Sewer: Gravity Sewer Systems, Sewer Force Mains, Directional Bore
(4). Water Distribution: Potable Water Systems, Water Service Systems
(5). Irrigation: Underground Irrigations Systems, Agricultural Systems
(6). Rehabilitation: Slip Lining, Pipe Bursting
(7). Reclaimed Water: Water Re-processing Systems
(8). Mining: Liquid Chemical Mining, Slurry and Tailing Lines, Mineral Extract System
(9). Geo-thermal Heating/Cooling: Heating/Cooling System for home and business
HDPE PIPE demension
HDPE WATER SUPPLY PIPE (PE 100) SPECIFICATION | |||||
EXECUTIVE STANDARD:GB/T13663-2000 THICKNESS:MM | |||||
NOMINAL PRESSURE | 0.6Mpa | 0.8Mpa | 1.0Mpa | 1.25Mpa | 1.6Mpa |
STANDARD SIZE RATIO | SDR26 | SDR21 | SDR17 | SDR13.5 | SDR11 |
NOMINAL OD | |||||
16 | 2.0 | ||||
20 | 2.0 | 2.3 | |||
25 | 2.3 | 3.0 | |||
32 | 2.3 | 2.4 | 3.0 | ||
40 | 2.3 | 2.3 | 3.0 | 3.7 | |
50 | 2.3 | 2.9 | 3.7 | 4.6 | |
63 | 2.3 | 2.5 | 3.6 | 4.7 | 5.8 |
75 | 2.9 | 3.6 | 4.5 | 5.6 | 6.8 |
90 | 3.5 | 4.3 | 5.4 | 6.7 | 8.2 |
110 | 4.2 | 5.3 | 6.6 | 8.1 | 10.0 |
125 | 4.8 | 6.0 | 7.4 | 9.2 | 11.4 |
140 | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 |
160 | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 |
180 | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 |
200 | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 |
225 | 8.6 | 10.8 | 13.4 | 16.6 | 20.5 |
250 | 9.6 | 11.9 | 14.8 | 18.4 | 22.7 |
280 | 10.7 | 13.4 | 16.6 | 20.6 | 25.4 |
315 | 12.1 | 15.0 | 18.7 | 23.2 | 28.6 |
355 | 13.6 | 16.9 | 21.1 | 26.1 | 32.2 |
400 | 15.3 | 19.1 | 23.7 | 29.4 | 36.3 |
450 | 17.2 | 21.5 | 26.3 | 33.1 | 40.9 |
500 | 19.1 | 23.9 | 29.7 | 26.8 | 45.4 |
560 | 21.4 | 26.7 | 33.2 | 41.2 | 50.8 |
630 | 24.1 | 30 | 37.4 | 46.3 | 57.3 |
710 | 27.2 | 33.9 | 42.1 | 52.2 | |
800 | 30.6 | 38.1 | 47.4 | 58.8 | |
900 | 34.4 | 42.9 | 53.3 | ||
1000 | 38.2 | 47.7 | 59.3 | ||
1200 | 45.9 | 57.2 | 70.6 | ||
1400 |
Processing workshop
Shipping details
Main products of Luoyang Max Corportion
Our customers from different countries
Dynamic Team of Luoyang Max Company
To provide the best products and service for our customers is what we have been pursuing and doing,quality is our baseline,reputation is what we cherish and we guarantee it. Call us now!!!
Joe: +86 18838855096
Skype: joe1989812
Luoyang Max Import & Export Trading CO.,Ltd welcomes your inquiry and visit!
