Marine Product Floats, MDPE Dredging Plastic Floats

Marine Product Floats, MDPE Dredging Plastic Floats thumbnail-1
Marine Product Floats, MDPE Dredging Plastic Floats photo-1
US$ 30 - 300 MOQ: 30 Sets
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
MAX
Model Number:
PIPE FLOATER
Contact Supplier Request Quote Chat Now
Luoyang Max Import Export Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name MAX
Model Number PIPE FLOATER
Plastic Modling Type Rotational molding

Specifications

plastic floats
1.good buoyancy
2.long life-span
3.light weight
4.various diameter

Marine Product Floats, MDPE Dredging Plastic Floats



Brief Introduction of FLOATER:
The hull of MDPE FLOATER is made from medium density polyethylene material with excellent flexibility, filled with high strength polyurethane foam inside. With reasonable structure and good performance, the MDPE floater becomes the ideal substitution of the traditional steel floater for the floating dredging pipes.

Marine Product Floats, MDPE Dredging Plastic Floats



Main Features of MDPE Floater:
1. Good flexibility, excellent impact resistance, particularly suitable for constructions in open sea;
2. Easy to install and handle, lower costs for moving;
3. Higher corrosive resistance, longer working life, 3 times longer than steel floaters;
4. Lower costs, the cost performance is better than steel floaters.

Applications:
1.Used in dredging sand pipeline;
2.It can be used in dredger, dredging pipe etc. in the sea, lake or river;
3.Particular used in laying the pipes on the water used in dredger project.

Marine Product Floats, MDPE Dredging Plastic Floats

Remarks:
1. 2 pieces of floaters form 1 set, 2 sets of floaters form 1 pair. 1 pair of floaters could float 6 meter long steel dredging pipe and 1.5m long rubber hose.
2. The floaters under the size of O.D4m*L4m are all available.



 Structure of Pipe Floater

No.

Structure Name

Material

1

Polyethylene Hull

Polyethylene

2

Hard Polyurethane Foam

Closed-cell Polyurethane

3

Steel Bolts & Nuts

Metal



























Connection way: bolts & nuts

Marine Product Floats, MDPE Dredging Plastic Floats





Specification table of Pipe Floater

PIPE OD(mm) FLOATER ID(mm) FLOATER OD(mm) FLOATER LENGTH(mm) FLOATER THICKNESS(mm) NET BUOYANCE(kg) FLOATER WEIGHT(kg)
50 60 300 500 7 80 10
159 220 500 800 7 200 16
205 220 500 800 7 200 16
219 220 500 800 7 200 16
273 300 700 1200 7 420 43
300 300 700 1200 7 420 43
325 375 1100 1100 7 920 72
350 375 1100 1100 7 920 72
400 414 1100 1200 8 1020 76
426 430 1200 1200 8 1200 93
450 480 1300 1300 8 1500 116
500 580 1400 1500 9 2219 170
536 580 1400 1500 9 2219 170
600 630 1400 1700 11 2400 182
630 630 1400 1700 11 2400 182
650 680 1480 1800 11.5 2930 210
700 730 1600 1900 12 3593 230
750 780 1600 2000 13 3800 245
800 830 1800 2000 14 4800 310
850 880 1800 2200 15 5140 380
900 940 2200 2500 16 8180 420
