Home > Products > LDR Sensor > Big Light Resistance 50-100Kohms GL5639 CDS Photoconductive Cell

Big Light Resistance 50-100Kohms GL5639 CDS Photoconductive Cell

FOB Price

Negotiable / Piece

1000 Pieces(Min. Order)

Port shenzhen

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	Senba
Model Number	GL5639	Type	Other, Photoresistor, GL5639
Technology	Metal Oxide	Package Type	Throught Hole
Resistance	50-100kohms	Resistance Tolerance	0.1
Rated Power	100mw	Temperature Coefficient	see following
Operating Temperature	-30~70

Product Description

Specifications

CDS Photoconductive Cell GL5639
Good reliability
Small volume
High sensitivity,Fast response
Good spectrum characteristic

Big Light Resistance 50-100Kohms GL5639 CDS Photoconductive Cell

Photoresistor is a resistor which made of semi-conductor material,and the conductance changes with luminance variation .The photoresistor can be manufactured with different figures and illuminate area based on this characteristic.

Performances and Features

Coated with epoxy

Good Reliability

High Sensitivity

Small Volume

Fast Response

Good Spectrum Characteristic

Applications

Switch

Light control

Electronic toy

Light control lamp

Photoelectric control

Industrial control

Camera automatic photometry

Annunciator

Types and Specifications

Specification	Type	Max. Voltage	Max. power	Environmental temp.	Spectrum peak value (nm)
φ5 series	GL5606	150	100	-30~+70	560
	GL5616	150	100	-30~+70	560
	GL5626	150	100	-30~+70	560
	GL5637-1	150	100	-30~+70	560
	GL5637-2	150	100	-30~+70	560
	GL5639	150	100	-30~+70	560
	GL5649	150	100	-30~+70	560

Specification	Light resistance (10Lux) (KΩ)	Dark resistance (MΩ)	r100/10	Response time (ms)		luminance resistance Fig. No.
Specification	Light resistance (10Lux) (KΩ)	Dark resistance (MΩ)	r100/10	Increase	Decrease	luminance resistance Fig. No.
φ5 series	4-7	0.5	0.5	30	30	2
	5-10	0.8	0.6	30	30	2
	10-20	2	0.6	30	30	3
	20-30	3	0.7	30	30	4
	30-50	4	0.8	30	30	4
	50-100	8	0.9	30	30	5
	100-200	15	0.95	30	30	6
