PE Mining Pipe and Pipe Fittings Sizes
US$ 2 - 200
MOQ: 50 Meters
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
MAX
Model Number:
HDPE PIPE
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
20mm to 1600mm Pe100 Black Hdpe Pipe Price List for Mining Quality ChoiceUS$ 0.8 - 400MOQ: 10 Meters -
Pe100 Hdpe Pipes Mining Slurry Pipe DN 250mm PN16 PipeUS$ 0.8 - 400MOQ: 10 Meters
-
Red Stripes Black PE100 12" HDPE Pipe Prices for MiningUS$ 50 - 75MOQ: 100 Meters
-
HDPE Pipes 300mm Mining Tailings Discharge PipesUS$ 2 - 200MOQ: 50 Meters
-
Mining Pipe, Wear Resistance HDPE Pipe Used to Transport Mining TailingsUS$ 2 - 200MOQ: 50 Meters
Place of Origin
Henan, China
Brand Name
MAX
Model Number
HDPE PIPE
Material
PE
Specification
20mm-1400mm
Length
6m, 12m or as required
Thickness
2mm-82mm
Standard
ISO9001 CE certificate
Specifications
pe mining pipeMaterial: PE80, PE100
PN Grade: 0.6-1.6Mpa
advantage:wear resistance
PE Mining Pipe and Pipe Fittings Sizes
Characteristics of pe mining pipe:
1.Long Lifespan
It can be used for more than 50 years under normal condition.
2.Good Sanitary Performance
It isn’t added the heavy metal salt stabilizer, and its material is non-toxic, does not scale. it is not easy to form dirt, and avoids secondary pollution of drinking water.
3.Excellent Wear Resistance
Its wear resistance is 4 times higher than steel pipe under normal conditions
4.Good Corrosion Resistance
It can resist variety of chemical mediator except few oxidants.
5.Little Coefficient of Friction and Low Flow Resistance
Inside sleek, low friction coefficient, medium circulation ability raise, excellent wear resistance.
6.Fine Flexibility and Anti-scratch Ability
7.Good Crack Growth Resistance
8.Simple Connection
Two pipes were connected by flanges.
9.Good Solder Ability
Its interface strength is higher than the pipe body.
Application of HDPE Pressure Pipe:
1.City and town water supply system or project;
2.To transport natural gas & coal gas in daily life;
3.Transport sand, mud, slurry for dredger in dredging projects or sand suction projects;
4.Food & chemical industry;
5.To transport ore & tailings;
6.To replace cement pipe, cast iron pipe & steel pipe;
7.Landscaping pipeline.
1.Long Lifespan
It can be used for more than 50 years under normal condition.
2.Good Sanitary Performance
It isn’t added the heavy metal salt stabilizer, and its material is non-toxic, does not scale. it is not easy to form dirt, and avoids secondary pollution of drinking water.
3.Excellent Wear Resistance
Its wear resistance is 4 times higher than steel pipe under normal conditions
4.Good Corrosion Resistance
It can resist variety of chemical mediator except few oxidants.
5.Little Coefficient of Friction and Low Flow Resistance
Inside sleek, low friction coefficient, medium circulation ability raise, excellent wear resistance.
6.Fine Flexibility and Anti-scratch Ability
7.Good Crack Growth Resistance
8.Simple Connection
Two pipes were connected by flanges.
9.Good Solder Ability
Its interface strength is higher than the pipe body.
Application of HDPE Pressure Pipe:
1.City and town water supply system or project;
2.To transport natural gas & coal gas in daily life;
3.Transport sand, mud, slurry for dredger in dredging projects or sand suction projects;
4.Food & chemical industry;
5.To transport ore & tailings;
6.To replace cement pipe, cast iron pipe & steel pipe;
7.Landscaping pipeline.
Specificate Table of HDPE Pipe
|
Nominal External Diameter dn, mm |
PE80 |
PE100 |
||
SDR17.6 |
SDR11 |
SDR17.6 |
SDR11 |
|
|
Pressure Nominal PN≤0.2 MPa |
Pressure Nominal PN≤0.4 MPa |
Pressure Nominal PN≤0.6 MPa |
Pressure Nominal PN≤1.0 MPa |
|
|
Nominal Thickness en,mm |
Nominal Thickness en,mm |
Nominal Thickness en,mm |
Nominal Thickness en,mm |
|
20 |
2.3 |
3 |
2.3 |
3 |
25 |
2.3 |
3 |
2.3 |
3 |
32 |
2.3 |
3 |
2.3 |
3 |
40 |
2.3 |
3.7 |
2.3 |
3.7 |
50 |
2.9 |
4.6 |
2.9 |
4.6 |
63 |
3.6 |
5.8 |
3.6 |
5.8 |
75 |
4.3 |
6.8 |
4.3 |
6.8 |
90 |
5.2 |
8.2 |
5.2 |
8.2 |
110 |
6.3 |
10 |
6.3 |
10 |
160 |
9.1 |
14.6 |
9.1 |
14.6 |
200 |
11.4 |
18.2 |
11.4 |
18.2 |
250 |
14.2 |
22.7 |
14.2 |
22.7 |
280 |
15.9 |
25.4 |
15.9 |
25.4 |
315 |
17.9 |
28.6 |
17.9 |
28.6 |
355 |
20.2 |
32.3 |
20.2 |
32.3 |
400 |
22.8 |
36.4 |
22.8 |
36.4 |
450 |
25.6 |
40.9 |
25.6 |
40.9 |
500 |
28.4 |
45.5 |
28.4 |
45.5 |
560 |
31.9 |
50.9 |
31.9 |
50.9 |
630 |
35.8 |
57.3 |
35.8 |
57.3 |
