Specifications
1. Excellent performance2. High efficiency
3. Energy-saving
4 .Safety and easy to operate
5. Environment-friendly
Medium Frequency Induction Heating Power Supply
1. Excellent performance
2. High efficiency
3. Energy-saving
4 . Safety and easy to operate
5. Environment-friendly
Medium Frequency Induction Heating Power Supply
Main parameters:
Model: |
DD-15II |
Maximum oscillating power: |
15KVA |
Input voltage scope: |
Single phase 180V-245V |
Input voltage frequency: |
50HZ-60HZ |
Output oscillating frequency: |
30KHZ-100KHZ |
Heating/retain current: |
200A-600A |
Heating/retain/cooling time: |
1S-99S |
Duty cycle: |
90% |
Cooling water flow: |
>6L/MIN |
Cooling water temperature: |
<45°C |
Weight: |
Controller:20.5Kg |
Medium Frequency Induction Heating Power Supply
Main characteristics applications:
This series is suitable for the heating of small metal parts, for example, (1)brazing of machining tools (2)Brazing of diamond tools (3)Heat treatment of small parts (4)Melting of gold, silver, copper, brass of little amount (5)Melting of steel stainless steel of little amount (6)Brazing of copper & brass tube connectors in air conditioner manufacturing factories so on. (7) Brazing of electrical kettle bottom
This series machines are characterized with simple structure, high reliability low price, are one of the most popular models have been used widely in every areas of metal heating.
Medium Frequency Induction Heating Power Supply
