Water Flow Meter

Water Flow Meter thumbnail-1
Water Flow Meter photo-1
US$ 300 - 900 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Cowell
Contact Supplier Request Quote Chat Now
Shanghai Cowell Machinery Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Cowell

Electromagnetic Flow Meter/ /flow meter/water flow meter/gas flow meter

Suitable tube caliber: DN25~DN2600(below DN25 unstandard)
Electrode material: 316L(stainless steel), HC, HB, Ti, Ta
Suitable Medium: Liquid with conductive ratio more than 5 μs/cm
Measuring range: 0.1~10m/s (extendable to 15m/s)
Upper limit of span: 0.5~10m/s. 1~5m/s recommended
Accuracy class: 0.3, 0.5, 1.0
Output signal: 4~20mADC, load≤ 750Ω, 0~3kHz, 5V with source and changeable width. High terminal and effective frequency output, RS485 interface
Operation pressure: 1.0MPa, 1.6MPa, 4.0MPa, 16MPa (special)
Fluid temperature: 20C~80C, 80C~130C, 130C~180C according to liner material
Environmental temperature:  sensor40~80º C. Transducer 15~50º C
Environmental humidity: ≤85%RH (at 20º C)

Cable outlet size: M20x1.5
Power supply: 220VAC± 10%, 50Hz± 1Hz, 24VDC± 10%
Power consumption: ≤8W
Protection ratings  Combined type: IP65. Separate type: Sensor IP68, transducer IP65
Materials of liner: PTFE, soft rubber etc
Connection of flange: GB911988(DIN2051, BS4504)
Earthing material: 1Cr18Ni9Ti (stainless steel), HC, Ti, Ta, Cu
