Home > Products > Flow Meter > 150mm 6 inch digital diesel fuel flow meter water
150mm 6 inch digital diesel fuel flow meter water
- 1000 Unit / Units per Month
- shanghai for 6 inch diesel fuel flow meter water
- Credit Card
- 6 inch fuel PD flow meter water with register counter
- Cowell digital positive displacement flow meter metering fuel,chemical, diesel
- Diesel fuel PD flow meter with printer
- LPGX filter& air eliminator for fuel flow meter by cowell
- FL Air Eliminator for fuel flow meter by cowell
- cowell 3" 80mm Water and oil Flow Meter with register strainer air eliminator can sell seprately
Product Details
Place of Origin: | Shanghai, China | Brand Name: | cowell | Model Number: | M-150-1 |
Packaging Details
Wooden Case for 6 inch diesel fuel flow meter water
Product Description
M Series Positive Displacement Flow Meter M-150-1 | |
M-150-1 Meter with Register Strainer & Air Eliminator
Characteristics Excellent stepless adjusting mechanism allows a micro adjustment on the meter; High accuracy and repeatability over the widest range of flow; Superior accuracy at constant flow; Low maintenance, no metal-to-metal contact in measuring chamber, long life service; Low pressure loss, a true gravity flow meter; Accuracy regardless of pressure fluctuations, temperature variation, viscosity.
| |
|
Technical Specification | |||||||||
Model | M-40-1 | M-50-1 | M-50H-1 | M-80-1 | M-80H-1 | M-100-1 | M-100H-1 | M-150-1 | M-150H-1 |
Size | 40mm /1.5” | 50mm / 2 " | 80mm / 3 " | 100mm / 4 " | 150mm / 6 " | ||||
Flow Range | 25-250 | 38-380 | 55-550 | 75-750 | 115-1150 | 130-1300 | 170-1700 | 225-2250 | 300-3000 |
Volume/Rev. | 0.309L | 0.681L | 1.839L | 5.102L | 9.507L | ||||
Max.Pressure | 10Bar/150PSI | 25Bar/350PSI | |||||||
Accuracy | ±0.2% | ||||||||
Repeatability | ≤0.05% | ||||||||
Standard Measurement | Liter / US Gallon/IMP Gallon | ||||||||
Viscosity | 30SSU~1,500,000SSU |
Note:4"&6" flange available for M-150/6" Meter.
Packaging Data | |||||
Model | M-40-1 | M-50-1 | M-80-1 | M-100-1 | M-150-1 |
Packaging | 1 pc/Wooden Case | ||||
Net Weight | 23Kgs | 26Kgs | 40Kgs | 70Kgs | 130Kgs |
Gross Weight | 35Kgs | 38Kgs | 55Kgs | 90Kgs | 155Kgs |
Size | 53×48×53cm | 53×48×53cm | 58×50×61cm | 76×64×72cm | 80×65×79cm |
Industries• Automotive; • Adhesives; • Agriculture; • Asphalt ; • Aviation fueling ; • Animal feeds; Beverage; • Cosmetics ; • Chemical processing; • Concrete Add mixtures; • Dairy; Liquid fertilizers; • Food processing ; • Fuel oil delivery; • General industrial; • Hydrocarbon processing; • Liquefied gases; • Lube oils; Marine; • Paint and varnish; • Petroleum marketing; • Petroleum production ; • Pharmaceutical; • Printing ink; • Pulp &paper; • Refining commercial Solvents; • Recycling Railroad ; • Textile. | Application• Refined petroleum products; • Aviation gasolines and jet fuels; • A wide variety of products such as: liquid sugars, corn syrup, corn sweetners, dextrose,fructose, sucrose, maltose, lactose, corn oil, soy bean oil, cotton seed oil, coconut oil; • Treated waters (deionized, demineralized, and potable); • Chlorinated solvents and general solvent metering; • Acid pH liquids; • Liquefied petroleum gas(LPG); • Crude oil, also for heated and/or viscous liquids; • Oil or water based latex products, polyester resins, and adhesives (neutral pH), also for metering herbicides and nitrogen fertilizer solutions; • Herbicide; • Sodium hydroxide (caustic) solutions, high sulfur crude oil (LACT and NOD) and other alkaline pH liquids; • Abrasive liquids. |
FAQ
How to contact us?
Please add our webchat:y303154623y
online chat skype:yanchen287
Company Profile
Shanghai Cowell Machinery Co., Ltd. (Cowell) is a professional manufacturer of petroleum tank truck equipment, industrial flow meters and pumps in China.
Registered in Shanghai, and managed by a professional team, Cowell delivers quality, efficiency, and expertise to our clients worldwide, being dedicated to providing the below full line products:
1) Fuel and LPG equipment - positive displacement flow meters and pumps, loading and unloading meters and pump nozzles
2) Fuel and LPG dispenser components - LPG meters, pumps, nozzles, separators, manometers, solenoid valves, differential valves, hoses and other related products
3) Tank Truck Spare Parts - manhole covers, bottom valves, manual brackets, API adapters, vapor recovery adaptors and other related products
4) Ultrasonic flow meters, turbine flow meters, intelligence electromagnetic flow meters, target mode flow meters (for liquid, gas and steam - high and low temperature and normal temperature).
5) We also offer sourcing of other products and consolidate with ours' accourding to our customers' demand.
If you are interested in our products, please do not hesitate to contact us for further information.
Contact Us
- Shanghai Cowell Machinery Co., Ltd.
- Contact nameGloria Chi
- Phone0086-21-36031183
- AddressRoom 803, No. 46, Lane 423, Xincun Road
