Contact Platform Support
Help CenterFuel Measuring Instrument
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
cowell
Model Number:
M series
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai for digital water flow meter
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
cowell
Model Number
M series
digital water flow meter
Characteristics
• Excellent stepless adjusting mechanism allows a micro adjustment of the meter
• High accuracy and repeatability over the widest range of flow; Superior accuracy
at constant flow
at constant flow
• Low maintenance, no metal-to-metal contact in measuring chamber, long life service
• Low pressure loss, a true gravity flow meter
• Accuracy regardless of pressure fluctuations, temperature variation, viscosity
• Choice of aluminum, cast iron and stainless steel materials of construction
Technical Specification | |||||||||
Model |
M-40-1 |
M-50-1 |
M-50H-1 |
M-80-1 |
M-80H-1 |
M-100-1 |
M-100H-1 |
M-150-1 |
M-150H-1 |
Size |
40mm / 1.5” |
50mm / 2 " |
80mm / 3 " |
100mm / 4 " |
150mm / 6 " |
||||
|
Flow Range (L/Min) |
25-250 |
38-380 |
55-550 |
75-750 |
115-1150 |
130-1300 |
170-1700 |
225-2250 |
300-3000 |
Volume /Rev. |
0.309L |
0.681L |
1.839L |
5.102L |
9.507L |
||||
Max. Pressure |
10Bar/150PSI |
25Bar/350PSI |
|||||||
Accuracy |
±0.2% |
||||||||
Repeatability |
≤0.05% |
||||||||
Standard Measurement |
Liter / US Gallon/IMP Gallon |
||||||||
Viscosity |
30SSU~1,500,000SSU |
||||||||
