Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > SC/ST/FC/LC PC/APC/UPC Fibre Optic Attenuator

SC/ST/FC/LC PC/APC/UPC Fibre Optic Attenuator

SC/ST/FC/LC PC/APC/UPC Fibre Optic Attenuator thumbnail-1
SC/ST/FC/LC PC/APC/UPC Fibre Optic Attenuator photo-1
US$ 0.1 - 5 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HX
Model Number:
LC
Contact Supplier Request Quote Chat Now
Shenzhen Hanxin Communication Optical Fiber Cable Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HX
Model Number LC

Specifications

Application
Telecommunications networks
Lan, Wan
CCTV networks
FTTX for end-to-end fibre cable connectivity




Product Description

   1. Description

    •  Telecom applications, single mode and multi mode type
    •  Fibre optic attenuators ST, SC, LC,FC, MTRJ, SMA, E2000, MU
    •  Available in PC, UPC and APC
 2. Application
  1. Telecommunications networks
  2. Lan, Wan
  3. CCTV networks
  4. FTTX for end-to-end fibre cable connectivity
3. Optical Characteristics

  G.652 G.655 50/125μm 62.5/125μm
Attenuation @850nm     ≤3.0 dB/km ≤3.0 dB/km
(+20°C) @1300nm     ≤1.0 dB/km ≤1.0 dB/km
  @1310nm ≤0.36 dB/km ≤0.40 dB/km
  @1550nm ≤0.22 dB/km ≤0.23dB/km
Bandwidth (Class A) @850nm     ≥500 MHz·km ≥200 MHz·km
@1300nm     ≥1000 MHz·km ≥600 MHz·km

Fiber color code:
SC/ST/FC/LC PC/APC/UPC fibre optic attenuator


Note: A:The color of fiber in loose tube is arranged from NO.1 color successively.
B:Other color indentifications available on request

Structure:
 SC/ST/FC/LC PC/APC/UPC fibre optic attenuator

4. Technical Parameters

Item

Unit

Parameter

Operating Wavelength

Nm

1310-1550

Attenuation Range

dB

1-10dB(1dB step),15,20,25,30dB

Return Loss

dB

PC:≥50   UPC:≥55   APC:≥60

Attenuation Tolerance

dB

≤1.0(11-30dB)

Working Temperature

°C

-25~+75

Storage Temperature

°C

-40~+85




Packaging & Shipping

5. Packing& Shipping



  1. packing in bags, then put in cartons according to clients' need
  2. shipping by sea or air
SC/ST/FC/LC PC/APC/UPC fibre optic attenuator

Our Services

6. Services

Sample: Can provide by our factory

prist list: can provide by our salesperson

after-sales: one by one

contact:

Skype: Candy.Foo2

Mobile: +0086-13519684370




Company Information

7. Introduction



Shenzhen Hanxin Communication Optical Fiber Cable Co., Ltd is a factory who mainly produce optical fiber products:

1.Outdoor Fiber Optic Cable(GYXTW,GYFTY,GYTA,GYTS,ADSS,GYXTC8Y,GYTA53 etc.)

2.Indoor Fiber Optic Cable(Simplex/Duplex indoor cable,distribution box,break-out cable,waterproof cable etc.)

3.FTTH(bow-type access cable,self-supporting bow-type cable)

4.Fiber Patch Cord(SC,SC,LC,FC,MTRJ,MU etc.

5.Accessories:Fiber Patch Panel,Fiber Splice Closure,Fiber Media Converter,Fiber Adapter



SC/ST/FC/LC PC/APC/UPC fibre optic attenuator




FAQ

8. Certificate



Skype: Candy.Foo2

Send Inquiry to This Supplier

Message
0/5000
