Specifications
Installation: underground,aerial, duct and so ontype: for outdoor
1. Description
- Aerial optical fiber cable,unitube structure.
- CST Outdoor Aerial Optical Fiber Cable with Maximum Fiber Number of 24 Cores
- Strength Member: two Steel wire
- Fiber: can choose SM 9/125 or MM: 62.5/125 ,50/125, OM1,OM2,OM3,OM4
- Low dispersion and attenuation
- Good mechanical and temperature perfermance
- High strength loose tube that is hydrolysis resistance
- Special tube filling compound ensure a critical protection of fiber
- With small cable diameter, light cable weight
- Crush resistance and flexibility
- The following measures are taken to ensure the cable watertight:
| G.652 | G.655 | 50/125μm | 62.5/125μm | ||
| Attenuation | @850nm | ≤3.0 dB/km | ≤3.0 dB/km | ||
| (+20°C) | @1300nm | ≤1.0 dB/km | ≤1.0 dB/km | ||
| @1310nm | ≤0.36 dB/km | ≤0.40 dB/km | |||
| @1550nm | ≤0.22 dB/km | ≤0.23dB/km | |||
Fiber color code:
Note: A:The color of fiber in loose tube is arranged from NO.1 color successively.
B:Other color indentifications available on request
| Cable Type | Fiber Count | Tubes | Cable Diameter | Cable Weight | Tensile Strength | Crush Resistance | Bending Radius |
| Long/Short Term | Long/Short Term | Static /Dynamic | |||||
| mm | kg/km | N | N/100mm | mm | |||
| CST-2~12 | 2~12 | 1 | 9 | 100 | 1000/3000 | 1000/3000 | 10D/20D |
| CST-14 ~24 | 14~24 | 1 | 9 | 120 | 1000/3000 | 1000/3000 | 10D/20D |
5. Packing& Shipping
- packing in Wooden drums, Polywooden drums or other drums according to clients' need
- shipping by sea or air
6. Services
Sample: Can provide by our factory
prist list: can provide by our salesperson
after-sales: one by one
contact:
Skype: Candy.Foo2
Mobile: +0086-13519684370
7. Introduction
Shenzhen Hanxin Communication Optical Fiber Cable Co., Ltd is a factory who mainly produce optical fiber products:
1.Outdoor Fiber Optic Cable(GYXTW,GYFTY,GYTA,GYTS,ADSS,GYXTC8Y,GYTA53 etc.)
2.Indoor Fiber Optic Cable(Simplex/Duplex indoor cable,distribution box,break-out cable,waterproof cable etc.)
3.FTTH(bow-type access cable,self-supporting bow-type cable)
4.Fiber Patch Cord(SC,SC,LC,FC,MTRJ,MU etc.
5.Accessories:Fiber Patch Panel,Fiber Splice Closure,Fiber Media Converter,Fiber Adapter
8. Certificate
