4 Core GYFTY Nylon Fibre Optic Cable

4 Core GYFTY Nylon Fibre Optic Cable thumbnail-1
4 Core GYFTY Nylon Fibre Optic Cable photo-1
US$ 0.1 - 5 MOQ: 1 Kilometer
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HX
Model Number:
GYFTY Nylon
Contact Supplier Request Quote Chat Now
Shenzhen Hanxin Communication Optical Fiber Cable Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HX
Model Number GYFTY Nylon

Specifications

Installation: underground,aerial, duct and so on
type: for outdoor




Product Description

   1. Description

  •  Duct optical fiber cable,stranded structure. anti-rodent
  •  GYFTY nylon Outdoor Aerial Optical Fiber Cable with Maximum Fiber Number of 288 Cores
  • Strength Member: FRP
  • Fiber: can choose SM 9/125 or MM: 62.5/125 ,50/125, OM1,OM2,OM3,OM4
 2. Characteristics
  1. Low dispersion and attenuation
  2. Good mechanical and temperature perfermance
  3. High strength loose tube that is hydrolysis resistance
  4. Special tube filling compound ensure a critical protection of fiber
  5. With small cable diameter, light cable weight
  6. Crush resistance and flexibility
  7.  The following measures are taken to ensure the cable watertight:
                     * Loose tube filling compound
                     * 100% cable core filling
3. Optical Characteristics

  G.652 G.655 50/125μm 62.5/125μm
Attenuation @850nm     ≤3.0 dB/km ≤3.0 dB/km
(+20°C) @1300nm     ≤1.0 dB/km ≤1.0 dB/km
  @1310nm ≤0.36 dB/km ≤0.40 dB/km
  @1550nm ≤0.22 dB/km ≤0.23dB/km
Bandwidth (Class A) @850nm     ≥500 MHz·km ≥200 MHz·km
@1300nm     ≥1000 MHz·km ≥600 MHz·km


Fiber color code:

4 core GYFTY nylon fibre optic cable

 Note: A:The color of fiber in loose tube is arranged from NO.1 color successively.

          B:Other color indentifications available on request

   Cable structure:

 4 core GYFTY nylon fibre optic cable
4. Technical Parameters
Nylon Cable Type Fiber Count Tubes Fillers  Cable Diameter Cable Weight   Tensile Strength Crush Resistance  Bending Radius
 Long/Short Term           Long/Short Term  Static /Dynamic
mm kg/km N N/100mm mm
GYFTY-2~12 2~12 1 4 10 255 1000/3000 1000/3000 10D/20D
GYFTY-14 ~24 14~24 2 3 10 255 1000/3000 1000/3000 10D/20D
GYFTY-26 ~36 26~36 3 2 10 255 1000/3000 1000/3000 10D/20D
GYFTY-38 ~48 38~48 4 1 10 255 1000/3000 1000/3000 10D/20D
GYFTY -50~60 50~60 5 0 10.5 255 1000/3000 1000/3000 10D/20D
GYFTY-62~72 62~72 6 0 11 255 1000/3000 1000/3000 10D/20D
GYFTY-74~84 74~84  7  0 11.5  255 1000/3000 1000/3000 10D/20D
GYFTY-86~96  86~96  8  0 12  300 1000/3000   1000/3000 10D/20D
GYFTY-98~108 98~108  9  0 12.5  300 1000/3000   1000/3000 10D/20D
GYFTY-110~120 110~120  10  0 12.8  300 1000/3000 1000/3000 10D/20D
GYFTY-122~132 122~132  11  0 13  300 1000/3000 1000/3000 10D/20D
GYFTY-134~144 134~144  12  0 13.2  300 1000/3000 1000/3000 10D/20D
... ... ... ... ... ... ... ... ...
GYFTY-276~288   276~288  12  0 15  300 1000/3000 1000/3000 10D/20D

Packaging & Shipping

5. Packing& Shipping



  1. packing in Wooden drums, Polywooden drums or other drums according to clients' need
  2. shipping by sea or air
4 core GYFTY nylon fibre optic cable

Our Services

6. Services

Sample: Can provide by our factory

prist list: can provide by our salesperson

after-sales: one by one

contact:

Skype: Candy.Foo2

Mobile: +0086-13519684370


Company Information

7. Introduction

Shenzhen Hanxin Communication Optical Fiber Cable Co., Ltd is a factory who mainly produce optical fiber products:

1.Outdoor Fiber Optic Cable(GYXTW,GYFTY,GYTA,GYTS,ADSS,GYXTC8Y,GYTA53 etc.)

2.Indoor Fiber Optic Cable(Simplex/Duplex indoor cable,distribution box,break-out cable,waterproof cable etc.)

3.FTTH(bow-type access cable,self-supporting bow-type cable)

4.Fiber Patch Cord(SC,SC,LC,FC,MTRJ,MU etc.

5.Accessories:Fiber Patch Panel,Fiber Splice Closure,Fiber Media Converter,Fiber Adapter

4 core GYFTY nylon fibre optic cable
