Small Light Milk Bottle Blow Moulding Machine
- Shanghai
- T/T
You May Like
-
Plastic Barrels Blow Moulding Machine,chemical Drum Blow Moulding Machine,plastic Chair Blow Moulding Machine
-
Plastic Barrels Blow Moulding Machine ,200 Litre Plastic Drum Blow Molding Machine , Plastic Pallet Blow Moulding Machine
-
Plastic Barrels Blow Moulding Machine,hdpe Drum Making Machine,plastic Chair Blow Moulding Machine
-
Plastic Barrels Production Machine, Plastic Pallet Blow Moulding Machine ,plastic Drum Making Machine
-
Plastic Drum Application Moulding Machine/ HDPE Drum Blowing Machine
-
Plastic Drum Application Molding Machine / HDPE Drum Blowing Machine
Product Details
| Condition | New | Application | Other, PE bottle, jerrycan | |
| Plastic Processed | Other, PE, PP, PVC, PC, ABS | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Jiangsu, China | |
| Brand Name | LONGWAYS | Model Number | LWB75D | |
| Voltage | 380V,440V,415V,220V | Power(W) | 65KW | |
| Dimension(L*W*H) | 4000*2300*2700mm | Weight | 6T | |
| Certification | CE | Warranty | 24 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
This is small light milk bottle blow moulding machine , A wide variety of materials can be used for the machine, which are suitable for producing 100ml to 5L PE bottle. The clamping system is a high-precision double-station linear guide, extrusion system using a hard gear reducer and inverter. The die head system adopts central-incoming extrusion die made of special steel, imported hydraulic valve and seal parts with proportional control valve.The control system consists of PLC and Human-machine interface imported from Japan, and automatic temperature control module and imported electrical parts.
hdpe milk bottles making machine production process
plastic hdpe milk bottles making machine specification
Unit | Item | Specification | Description |
Extruding system
| Screw diameter | Φ75mm | Mixing model |
Max. Product Volume | 1L | Double station and tetra die-head | |
Screw L/D | 24:1 |
| |
Material of screw and barrel |
| 38CrMoALA | |
Plasticizing capacity | 90KG/Hr | Based on HDPE 5502 | |
Extruding method |
| Inverter motor, hardness tooth surface gear box | |
Driving power | 30KW |
| |
Screw revolution | 10—90rpm |
| |
Heating zones | 3 | Temperature module from Mitsubishi PLC | |
Heating power | 10KW | Solid state (SSR) and plug connection for all heaters | |
Blowers | 3 |
| |
Cooling function | Yes | Cooling water for feeding zone and gear box |
plastic gallon blow molding machine extruder- die head
plastic gallon blow molding machine plastic plasticing part
plastic gallon blow molding machine product making step
Zhangjiagang plastic blow molding machine component brand
Zhangjiagang plastic blow molding machine, loading
Any inuqiry about plastic bottle machine maker , blow moulding machine, please contact us! thanks!
