Home > Products > 0-3L blow molding machine > Stable quality plastic extrusion blowing machine, 5 liter extrusion blowing machine for bottle, single head 5L blowing machine
Stable quality plastic extrusion blowing machine, 5 liter extrusion blowing machine for bottle, single head 5L blowing machine
- 45 Set / Sets per Month
- Shanghai
- T/T
-
High speed Plastic bottle making 0.5L- 2L 6000BPH Automatic PET bottle blow blowing mold molding machine prices
-
Factory Price High Quality Automatic Fast Plastic PP HDPE Bottle Blowiing Jerrycan Extrusion Blow Molding Machine
-
Semi Automatic PET Plastic Bottle 5 Gallon 20 Liter Blow Molding Machine Price
-
custom design semi-automatic preform pet plastic bottle blowing blow molding machine high speed
-
Semi-automatic Two Cavity Bottle Making Machine Blow Molding Equipment
-
Plastic bottle blowing machine Beverage bottle blowing machine Medicine bottle blowing machine
Product Details
| Condition: | New | Application: | Other, PE bottle, jerrycan, shampoo bottle | Plastic Processed: | Other, PE, PP, PVC, PC, ABS |
| Blow Moulding Type: | Extrusion Blow Moulding | Automatic: | Yes | Place of Origin: | Jiangsu, China |
| Brand Name: | LONGWAYS | Model Number: | LWB75D | Voltage: | 380V,440V,415V,220V |
| Power(W): | 65KW | Dimension(L*W*H): | 4000*2300*2700mm | Weight: | 6T |
| Certification: | CE | Warranty: | 24 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
This is Stable quality plastic extrusion blowing machine, 5 liter extrusion blowing machine for bottle, single head 5L blowing machine , A wide variety of materials can be used for the machine, which are suitable for producing 100ml to 5L PE bottle. The clamping system is a high-precision double-station linear guide, extrusion system using a hard gear reducer and inverter. The die head system adopts central-incoming extrusion die made of special steel, imported hydraulic valve and seal parts with proportional control valve.The control system consists of PLC and Human-machine interface imported from Japan, and automatic temperature control module and imported electrical parts.
Plastic double station blow moulding machine process
Plastic shampoo bottle blow moulding machine specification
Unit | Item | Specification | Description |
Extruding system
| Screw diameter | Φ75mm | Mixing model |
Max. Product Volume | 1L | Double station and tetra die-head | |
Screw L/D | 24:1 |
| |
Material of screw and barrel |
| 38CrMoALA | |
Plasticizing capacity | 90KG/Hr | Based on HDPE 5502 | |
Extruding method |
| Inverter motor, hardness tooth surface gear box | |
Driving power | 30KW |
| |
Screw revolution | 10—90rpm |
| |
Heating zones | 3 | Temperature module from Mitsubishi PLC | |
Heating power | 10KW | Solid state (SSR) and plug connection for all heaters | |
Blowers | 3 |
| |
Cooling function | Yes | Cooling water for feeding zone and gear box |
Plastic shampoo bottle blow moulding machine extruder- die head
Plastic detergent hdpe bottle blowing machinery detailed photos
Blow moulding machine component brand
Any inuqiry about blow molding machine, blow moulding machine, please contact us! thanks!
