UL 1430 Hook-Up Wire1).Rated temperature:105C
2).Rated Voltage:300V
3).Standard:UL subject 758,UL1581
4).Insulation:PVC
UL 1430 Hook-up Wire
Product Description
·Rated temperature:105
·Rated voltage:300V
·Standard:UL subject 758,UL 1581
·Conductor:30-16AWG,solid or stranded tinned or bare copper
·Insulation:Lead free irradiated PVC
·Passes UL VW-1 Vertical flame test
·Resistant to acid,alkali,oil,moisture and fungi
Application
For internal wiring of electronic and electrical equipment
Where exposed to temperatures not exceeding 80.
UL style |
Conductor |
Insulation |
Max.resistance of conductor at 20Ω/km |
Package |
|||||
|
AWG
|
Nom.Area
mm2 |
No/mm
|
Nom.Dia
mm |
Nom.Thick
mm |
Nom.Dia
mm |
ft/coil |
m/coil |
||
UL1430 |
28 |
0.0804 |
7/0.127 |
0.38 |
0.40 |
1.18 |
237.25 |
2000 |
610 |
26 |
0.128 |
7/0.16 |
0.48 |
1.28 |
148.94 |
2000 |
610 |
||
24 |
0.205 |
11/0.16 |
0.61 |
1.41 |
93.25 |
2000 |
610 |
||
22 |
0.324 |
17/0.16 |
0.76 |
1.56 |
55.0 |
2000 |
610 |
||
20 |
0.519 |
21/0.18 |
0.95 |
1.75 |
34.6 |
2000 |
610 |
||
18 |
0.823 |
16/0.254 |
1.17 |
1.87 |
21.8 |
2000 |
610 |
||
16 |
1.31 |
26/0.254 |
1.50 |
2.30 |
13.7 |
1000 |
305 |
||
Order reference
·Color:black,white,yellow,dark green,dark blue,brown,grey,orange,violet,yellow/green,special color also can be ordered.
·Specification:Reference to specification table,Special specification also can be ordered.
