Specifications
Polyolefin non-heat shrinkable tube1) Good thermal stability
2) Flexible, highly flame-retardant
3) High reliability
Polyolefin non-heat shrinkable tube
This product is environmentally friendly, flexible, flame-retardant, irradiated crosslinking not-heat-shrinkable modified polyolefin tubing. It is designed to provide protection, insulation and capsule of wire harnesses in automobile, electric and electronic facilities.
Features:
1) Good thermal stability
2) Flexible, highly flame-retardant
3) Excellent physical, chemical and electrical properties and high reliability
4) Free of PCBs, PCPs, polybrominated biphenyls (PBBs), polybrominated biphenyl
oxides and ethers (PBBOs, PBBEs and PBDEs) and toxic heavy metal compounds,
which are classified as environmentally hazardous substances
5) Conforms to European RoHS environmental directive
6) Wide range of sizes and colors
Operating temperature range:
a) Operating temperature range: -55 ~ 125°C
Standards and approvals: UL224 125°C VW-1
Specification values
|
Property |
Requirement |
Test method |
Typical data |
Physical |
Tensile strength |
10.4MPa min. |
ASTM D 638 |
≥14.0MPa |
|
Elongation |
200% min. |
ASTM D 638 |
≥400% |
|
Heat shock 250, 4hrs |
No cracking, dripping or flowing |
ASTM D 2671 |
Pass |
|
Low temperature flexibility -55, 4hrs |
No cracking |
ASTM D 2671 |
Pass |
|
Aging 158,168hrs |
|
|
|
|
Tensile strength after aging |
70% of original min. |
ASTM D 638 |
≥90% |
|
Elongation after aging |
100% min. |
ASTM D 638 |
≥300% |
|
Electrical |
Dielectric voltage withstand |
2500V, 60sec no breakdown |
UL224 |
Pass |
Dielectric strength |
19.7KV/mm min. |
ASTM D 2671 |
25KV/mm |
|
Volume resistivity |
1014Ω·cm min. |
ASTM D 876 |
≥1014Ω·cm |
|
Chemical |
Corrosion |
No corrosion |
ASTM D 2671 |
Pass |
|
Flammability |
VW-1 |
UL224 |
Pass |
Product sizes
|
Size AWG |
Inside diameter mm |
Wall thickness mm |
Standard length m/spool |
AWG18 |
1.00±0.10 |
0.40±0.06 |
400 |
AWG16 |
1.30±0.10 |
0.40±0.06 |
400 |
AWG14 |
1.65±0.10 |
0.40±0.06 |
400 |
AWG12 |
2.10±0.15 |
0.40±0.06 |
400 |
AWG10 |
2.60±0.15 |
0.50±0.06 |
400 |
AWG8 |
3.30±0.15 |
0.50±0.06 |
400 |
AWG6 |
4.10±0.20 |
0.50±0.06 |
200 |
AWG4 |
5.20±0.20 |
0.50±0.06 |
200 |
AWG2 |
6.50±0.20 |
0.50±0.06 |
100 |
AWG0 |
8.30±0.30 |
0.50±0.06 |
100 |
1/8 |
9.50±0.40 |
0.50±0.06 |
100 |
7/16 |
11.10±0.40 |
0.50±0.06 |
100 |
1/2 |
12.70±0.40 |
0.50±0.06 |
100 |
Ordering information:
a) Standard colors: black (-BK), white (-WH)
b) Nonstandard colors: available upon requests
c) Nonstandard size
d) Special sizes are available upon requests
e) Standard packaging
f) On spools
g) Specify product type, size (mm or inch) and color
