Medium wall heat shrink tube/heat shrinkable sleeve
Applications
This Medium wall heat shrinkable tubing with hot melt adhesive, having properties of excellent insulating, environmental sealing, and resistant to impact and abrasion, it is designed for applications to seal and protect electrical splices, cable terminations and joints where electrical insulation and water proof are required, 3:1 shrink ratio allows it easily fit over irregular shape and large connectors.
Feature
Shrinkable ratio:3:1
Easily fit over irregular shape and large connectors.
Resistant to UV and waterproof.
High electrical insulation.
Operating temperating:-55℃ to 110℃.
Minimum shrink temperature:80℃.
Minimum fully recovery temperature:120℃
Standard color: Black
Package
Technical Data:
Property |
Test Method |
Typical Data |
Operation temperature |
IEC 216 |
-55℃to110℃ |
Tensile strength |
ASTM D 2671 |
≥14MPa |
Elongation break |
ASTM D 2671 |
≥400% |
Density |
ASTM D 792 |
1.05g/cm3 |
Longitudinal shrinkage |
UL 224 |
0 to 10% |
Volume resistance |
IEC 93 |
>1014Ω.cm |
Eccentricity |
ASTM D 2671 |
≤30% |
Copper stability |
ASTM D 2671 |
Pass |
Production Size:
|
Normal size (mm) |
As supplied(mm) |
After recovered (mm) |
|
ID(Min.) |
ID(Max.) |
WT Min |
|
8/2 |
8 |
2 |
1.7 |
12/3 |
12 |
3 |
2.0 |
16/5 |
16 |
5 |
2.2 |
19/5 |
19 |
5 |
2.5 |
22/6 |
22 |
6 |
2.5 |
28/6 |
28 |
6 |
2.5 |
33/8 |
33 |
8 |
2.5 |
40/12 |
40 |
12 |
2.5 |
44/14 |
44 |
14 |
2.7 |
55/16 |
55 |
16 |
2.8 |
65/19 |
65 |
19 |
3.0 |
75/22 |
75 |
22 |
3.0 |
85/25 |
85 |
25 |
3.0 |
95/25 |
95 |
25 |
3.0 |
115/34 |
115 |
34 |
3.0 |
140/42 |
140 |
42 |
3.5 |
160/50 |
160 |
50 |
3.5 |
180/58 |
180 |
58 |
3.5 |
200/65 |
205 |
65 |
3.5 |
235/65 |
235 |
65 |
3.7 |
265/75 |
265 |
75 |
4.0 |
300/75 |
300 |
85 |
4.0 |
Company Information:
Guangzhou Kaiheng Enterprise Group Co.,Ltd was founded in 1998,and Guangzhou Kaiheng K&S Co.,Ltd is an affiliated company of the group,we are a very professional manfuacturer of PVC tube, heat shrinkable tube including medium wall&heavy wall heat shrinkable tube,Dual &single heat shrinkable tuble,
Busbar,Telflon heat shrinkable tube,and wire accessoies for 17 years.And we have over 10 years of exporting experience to overseas makerts.
