High quality polyolefin shrinkable insulation sleeves
Features/Benefits
·Shrink ratio: 2:1.
·Very flexible, highly flame-retardant.
·Low shrink temperature.
·Good thermal stability.
·Conform to RoHS environmental directive.
Operating Temperature Range
Operating temperature range: -55℃~125℃
Minimum shrink temperature: 70℃
Minimum full recovery temperature: 110℃
Standards/Approvals
UL224 E214175 125℃ 600V VW-1
CSA C22.2 210475 125 ℃ 600V VW-1
AMS-DTL-23053/5 class 1 and class 3
Metric size
Size(mm) |
As supplied(mm) |
After recovery (mm) |
Standard length (m/spool) |
||
Inside diameter |
Wall thickness |
Inside diameter(max.) |
Wall thickness(min.) |
||
φ0.8 |
1.0±0.2 |
0.15±0.05 |
0.50 |
0.25 |
200 |
φ1.0 |
1.5±0.3 |
0.20±0.05 |
0.60 |
0.33 |
200 |
φ1.5 |
2.0±0.3 |
0.20±0.05 |
0.75 |
0.36 |
200 |
φ2.0 |
2.5±0.3 |
0.20±0.05 |
1.00 |
0.44 |
200 |
φ2.5 |
3.0±0.3 |
0.25±0.05 |
1.25 |
0.44 |
200 |
φ3.0 |
3.5±0.3 |
0.25±0.05 |
1.50 |
0.44 |
200 |
φ3.5 |
4.0±0.3 |
0.25±0.05 |
1.75 |
0.44 |
200 |
φ4.0 |
4.5±0.3 |
0.25±0.05 |
2.00 |
0.44 |
200 |
φ4.5 |
5.0±0.3 |
0.25±0.05 |
2.25 |
0.44 |
200 |
φ5.0 |
5.5±0.3 |
0.25±0.05 |
2.50 |
0.56 |
100 |
φ6.0 |
6.5±0.3 |
0.28±0.05 |
3.00 |
0.56 |
100 |
φ7.0 |
7.6±0.3 |
0.30±0.06 |
3.50 |
0.56 |
100 |
φ8.0 |
8.6±0.3 |
0.30±0.06 |
4.00 |
0.56 |
100 |
φ9.0 |
9.6±0.3 |
0.30±0.06 |
4.50 |
0.56 |
100 |
φ10.0 |
10.7±0.4 |
0.30±0.06 |
5.00 |
0.56 |
100 |
φ11.0 |
11.7±0.4 |
0.30±0.06 |
5.50 |
0.56 |
100 |
φ12.0 |
12.7±0.4 |
0.30±0.06 |
6.00 |
0.56 |
100 |
φ13.0 |
13.7±0.4 |
0.35±0.07 |
6.50 |
0.69 |
100 |
φ14.0 |
14.7±0.4 |
0.35±0.07 |
7.00 |
0.69 |
100 |
φ15.0 |
15.7±0.5 |
0.35±0.07 |
7.50 |
0.69 |
100 |
φ16.0 |
16.7±0.5 |
0.35±0.07 |
8.00 |
0.69 |
100 |
φ18.0 |
19.0±0.5 |
0.40±0.10 |
9.00 |
0.77 |
100 |
φ20.0 |
21.0±0.5 |
0.40±0.10 |
10.00 |
0.77 |
50 |
φ22.0 |
23.0±0.5 |
0.40±0.10 |
11.00 |
0.77 |
50 |
φ25.0 |
26.0±1.0 |
0.45±0.10 |
12.50 |
0.87 |
50 |
φ28.0 |
29.0±1.0 |
0.45±0.10 |
14.00 |
0.87 |
50 |
φ30.0 |
31.5±1.0 |
0.45±0.10 |
15.00 |
0.87 |
50 |
φ35.0 |
36.5±1.0 |
0.50±0.10 |
17.50 |
0.97 |
50 |
φ40.0 |
41.5±1.0 |
0.50±0.10 |
20.00 |
0.97 |
50 |
φ50.0 |
51.5±1.0 |
0.55±0.10 |
25.00 |
0.97 |
50 |
Guangzhou Kaiheng K&S Co.,Ltd is a professional manufacturer &supplier of Heat Shrinkable Tubing offering good quality products at competitive price.We are specialized in this field for 17 years.We manufacture and distribute a broad range of heat shrinkable tube,PVC tube.
Trademarked as KOSOO. Our productsmeet international standards such as UL,CSA and Milspec as well as international environmental demands.
