Product Details
Place of Origin: | Guangdong, China | Brand Name: | KOSOO | Model Number: | K-2(HB) |
Type: | Other, Insulation Sleeving, heat shrinkable tube | Material: | Other, Polyolefin | Application: | Low Voltage |
Rated Voltage: | 600V | Tensile Strength: | ≥14.0MPa |
Product Description
Environment friendly and flame retardant heat shrinkable tubing.
1.Application
KOSOO K-2 is environment friendly, flexible, flame-retardant, irradiated crosslinking heat-shrinkable modified polyolefin tubing. Unlike other typical flame-retarant tubings,This high-reliability product is widely used for insulation or jacketing of wire harness, strain relief of wire terminations and connections, bundling of wire harness, protection of soldered points, insulation and capsule of electronic components, anti-corrosive protection, identification and color coding, etc.
2.Features/Benefits
·Shrink ratio: 2:1.
·Very flexible, highly flame-retardant.
·Low shrink temperature.
·Good thermal stability.
·Excellent physical, chemical and electrical properties.
3.Operating Temperature Range
Operating temperature range: -55°C~125°C
Minimum shrink temperature: 70°C
Minimum full recovery temperature: 110°C
4.Standards/Approvals
UL224 E214175 125 600V VW-1
CSA C22.2 210475 125 600V VW-1
AMS-DTL-23053/5 class 1 and class 3
5. Product sizes
Size (inch) | Inside diameter (mm/inch) | Wall thickness (mm/inch) | Standard length (m/spool) | |
As supplied(min.) | After recovery(max.) | After recovery | ||
3/64 | 1.20.046 | 0.60.023 | 0.40±0.080.016±0.003 | 200 |
1/16 | 1.60.063 | 0.80.031 | 0.43±0.080.017±0.003 | 200 |
3/32 | 2.40.093 | 1.20.046 | 0.51±0.080.020±0.003 | 200 |
1/8 | 3.20.125 | 1.60.062 | 0.51±0.080.020±0.003 | 200 |
3/16 | 4.80.187 | 2.40.093 | 0.51±0.080.020±0.003 | 100 |
1/4 | 6.40.250 | 3.20.125 | 0.64±0.080.025±0.003 | 100 |
3/8 | 9.50.375 | 4.80.187 | 0.64±0.080.025±0.003 | 100 |
1/2 | 12.70.500 | 6.40.250 | 0.64±0.080.025±0.003 | 100 |
3/4 | 19.10.750 | 9.50.375 | 0.76±0.080.030±0.003 | 50 |
1 | 25.41.000 | 12.70.500 | 0.89±0.120.035±0.005 | 50 |
1 1/4 | 31.81.250 | 15.90.625 | 1.02±0.150.040±0.006 | 50 |
1 1/2 | 38.11.500 | 19.10.750 | 1.02±0.150.040±0.006 | 50 |
2 | 50.82.000 | 25.41.000 | 1.14±0.160.045±0.007 | 50 |
Metric size: ID from 1.0mm to 150mm, all available.
6.Ordering Information
1) Color
Standard: Black (-BK), white (-WH), red (-RD), blue (-BL), yellow (-YL), green (-GR)
Nonstandard: Brown (-BR), orange (-OR), violet (-VT), gray (-GY), yellow & green stripe (-GYS)
Specify product type, size (mm or inch) and color
Company information
Guangzhou Kaiheng Enterprise Group Co.,Ltd was founded in 1998,and Guangzhou Kaiheng K&S Co.,Ltd is an affiliated company of the group,we are a very professional manfuacturer of PVC tube, heat shrinkable tube including medium wall&heavy wall heat shrinkable tube,Dual &single heat shrinkable tuble,Busbar,Telflon heat shrinkable tube,and wire accessoies for 17 years.And we have over 10 years of exporting experience to overseas makerts.
