AC690 1200Mbps 802.11AC Dual-Band Wireless Access Point
AC690
AC690 Wireless 802.11AC Dual Band Router ( Wireless access point, Four-ports gigabit switch and firewall in one), ideal for home and SOHO users to share Internet connection over the wired and wireless network. Works over 2.4G and 5G and delivers up to 300 Mbps +867Mbps with reduced interference.It supports Disk Management, User Management,Samba Server, FTP Server.
Features
1.IEEE 802.11ac/a/b/g/n compliance
2.Integrates 100m router, Wireless access point, Four-ports switch and firewall in one
3.Concurrent Dual Band: Works over 2.4G and 5G and delivers up to 300 Mbps +867Mbps with reduced interference
4.4x10/100/1000Mbps LAN Port, 1x10/100/1000Mbps WAN Port
5.Provides one USB 2.0 interface
6.Supports printer server
7.Supports Disk Management, User Management, Samba Server, FTP Server
8.4x5dBi Fixed Antenna
9.WDS Wireless Bridge
10.Built-in firewall, Filtering on IP address, MAC address, Domain name, Applications, etc
11.Supports 64/128-bits WEP, WPA/WPA2 Encryption
Specification
Standard |
2.4GHz:IEEE802.11n, IEEE802.11g,IEEE 802.11b |
Interface |
LAN 4 10/100/100M Auto MDI/MDIX RJ45 port WAN 1 10/100/100M Auto MDI/MDIX RJ45 port 1 USB 2.0 port |
Frequency Range |
2.4GHz,5GHz |
Wireless Speed |
2.4G: 300Mbps |
Spread Spectrum |
DSSS |
Modulation |
BPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM) |
Transmission Distance |
Indoor up to 100m , outdoor up to 300m (it is limited in an environment) |
Receive Sensitivity@PE |
11ac : -68dBm@10% PER 11a : -68dBm@10% PER 11n : -70dBm@10% PER 11g : -72dBm@10% PER 11b: -85dBm@8% PER |
Transmit Power |
17dBm |
Antenna |
4x5dBi Fixed Antenna |
LED Indicator |
Status |
Data Security |
64/128-bits WEP; WPA/WPA2 |
Environment |
Operating Temperature: 0°C~40°C (32°F~104°F) Operating Humidity: 10%~90%RH (non-condensing) |
Power |
12V/ 1A |
Dimensions (L*W*H)mm |
184mmx135mmx25mm |
Safety & Emission |
FCC, CE |
Pictures
Global shows
Our workshop
Certifications
Quality and warranty
All our products are checked quality passed before delivery. Besides we provide TWO YEAR WARANTY for defective items if any.
