2016 Factory Stock OEM Accepted 300Mbps Wifi Router 1LAN 4Wan Wireless Router
1.IEEE 802.11n compliance. Backwards compatible with 802.11b/g
2.Integrates router, Wireless access point, Four-ports switch and firewall in one
3.2.4GHz, wireless transmit rates up to 300Mbps (2T2R)
4.4x10/100Mbps LAN Port, 1x10/100Mbps WAN Port
5.2x5dBi Fixed Antenna
6.WDS Wireless Bridge
7.Built-in firewall, Filtering on IP address, MAC address, Domain name, Applications, etc
8.Supports 64/128-bits WEP, WPA/WPA2 Encryption
Standard |
IEEE 802.11n,IEEE 802.11g,IEEE 802.11b IEEE 802.3,IEEE 802.3u |
Interface |
LAN 4 10/100M Auto MDI/MDIX RJ45 port WAN 1 10/100M Auto MDI/MDIX RJ45 port |
Frequency Range |
2.4GHz-2.4835GHz |
Wireless Speed |
300Mbps |
SOC Chipset |
RTL8196E |
CPU Clock Rate |
400MHz |
2.4GHz RF Chipset |
RTL8192ER |
10/100 Switch |
RTL8196E |
Flash |
4MB |
Memory |
16MB |
Spread Spectrum |
DSSS |
Modulation |
BPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM) |
Wireless Mode |
Access Point ,Route mode ,Relay mode, WISP mode |
System Requirement |
Wired or wireless PC/Mac an available 802.11a/b/g/n wireless network |
Transmission Distance |
Indoor up to 100m , outdoor up to 300m (it is limited in an environment) |
Receive Sensitivity@PE |
11n : -70dBm@10% PER 11g : -72dBm@10% PER 11b: -85dBm@8% PER |
Transmit Power |
17dBm |
Antenna |
2x5dBi Fixed Antenna |
LED Indicator |
Status |
Data Security |
64/128-bits WEP; WPA/WPA2 |
Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉) Operating Humidity: 10%~90%RH (non-condensing) |
Power |
5V/ 1A |
Safety & Emission |
FCC, CE |
JCG is mainly focusing on the developing, manufacturing, marketing & services of Ethernet series products and Wireless networking products, such as10M-100M-1000Mbps Ethernet switches, router, Fiber converter, ADSL, Lan card series and wireless etc.
Our mission is to be the leading brand of smart wireless routers for small businesses and homes worldwide. Therefore we will constantly help our consumers worldwide to provide much more competitive edge wireless networking products.
Our factory is located at Yasen Innovative Technology Park, Longgang District, Shenzhen, China. 16000 square meters standard workshops, equipped with high-speed SMT lines and other advanced production equipments. JCG is committed to developing, manufacturing, marketing of smart wireless router and other related networking products.
Our office Address: 23F, C1 Building, Nanshan Zhiyuan, LiuXian Road, XiLi, Nanshan District, Shenzhen City, China.
We attand the German CEBIT, Taipei Computex, US CES annually.
All our products approved FCC,CE,RoHS.
Quality and warranty
All our products are checked quality passed before delivery. Besides we provide TWO YEAR WARANTY for defective items if any.
