Specifications
24port 10/100M Ethernet Switch1, good price
2, timely delivery
3, manufacturer since 1995
24port 10/100M switch
Detailed Product Description
1.24-port ethernet switch
2.24 port 10/100Mbps TX Auto-Negotiation
3.Factory price 4.FCC,CE,RoHS,GS
24-port ethernet switch
JES-1024I
JES-1024I 24-port ethernet switch is an Ethernet Switch with good quality and very favourable price. OEM service in large quantity is offered.
Product description
Specification
Characters
1. Compliant with the IEEE 802.3 10Base-T Ethernet, IEEE 802.3u 100Base-TX specifications
2. 24 port 10/100Mbps TX Auto-Negotiation Ethernet Switch
3. Automatic Source MAC Address Learning and Aging 4.IEEE 802.3x flow control for Full-duplex 5.Back Pressure function for 10/100Mbps Half-duplex operation 6.Plug and Play
Spec
Standard |
IEEE 802.3 10Base-T,IEEE 802.3u 100Base-TX IEEE 802.3x Flow Control |
Port |
24 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) |
Network Media |
10BASE-T: UTP Cat.3 or up 100BASE-TX: UTP Cat.5 or up |
Transmission Method |
Store and Forward |
Data Transfer Rate |
10/100M (Half-duplex) 10/100M (Full-duplex) |
Access Method |
CSMA/CD |
LED Indicators |
Power, Link/Act |
Environment |
Operating Temperature: 0°C~40°C Storage Temperature: -40°C~70°C Operating Humidity: 10%~90%RH(non-condensing) Storage Humidity: 5%~90%RH(non-condensing) |
Dimensions |
445mmx123mmx45mm |
Safety & Emission |
FCC, CE |
