SiRF Star IV High Accuracy RJ45 GPS Receiver GM1-86S4

SiRF Star IV High Accuracy RJ45 GPS Receiver GM1-86S4 thumbnail-1
SiRF Star IV High Accuracy RJ45 GPS Receiver GM1-86S4 photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Gps Receiver
Use:
Automotive
Screen Size:
Other, without screen
Contact Supplier Request Quote Chat Now
Shenzhen Xucai Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Gps Receiver
Use Automotive
Screen Size Other, without screen
Place of Origin Guangdong, China
Brand Name XUCAI
Model Number GM1-86S4

Specifications

2013 New Arrival~ SiRF Star IV high accuracy gps receiver GM1-86S4
1.SiRF Star IV
2.Extremely fast TTFF at low signal level

 SiRF Star IV High Accuracy RJ45 GPS Receiver GM1-86S4



Features:





1:SiRF Star IV high performance GPS Chipset
2:Highly sensitive (Tracking Sensitivity: -163    dBm)
3:Extremely fast TTFF (Time To First Fix) at low signal level
4:Support NMEA 0183 data protocol
5:Built-in SuperCap to reserve system data for rapid satellite acquisition
6:Super-cohensive magnetic for mounting on the car
7:Waterproof and non-slip on the bottom





Description





The GM1-S4 is a USB GPS receiver ,a highly sensitive, low power consumption chipset in a ultra compact form factor. The GM1-86S4 is powered by a SIRF Star IV GPS chipset, and will provide you with superior performance in urban canyons, and in dense foliage.

With the SiRF CGEE (Client Generated Extended Ephemeris) technology, it has the capability of predicting satellite positions for up to 3 days in advance, and will deliver a CGEE-start time of less than 15 seconds under most conditions without any network assistance. The GM1-86S4's MicroPower mode allows the receiver to stay in a hot startlike condition almost continuously while consuming very little power.





Specification





Some Parameters

Electrical Characteristics:
1.GPS Chipset: SiRF STAR IV GSD4e 2.Frequency L1, 1575.42 MHZ
3.C/A Code 1.023 MHz chip rate
4.Channels 48 all-in-view tracking
5.Sensitivity -163 dBm
Accuracy:
1.Position Horizontal <2.5m 2D RMS SBAS enable
2.10m 2D RMS WAAS disabled
3.Velocity 0.1m/sec 95% (SA off),
4.Time 1 micro-second synchronized to GPS time
5.WAAS Enabled for North America products
Acquisition Rate:
1.Hot start: 8 sec., average
2.Warm start 35 sec., average
3.Cold start 35 sec., average
4.Reacquisition 0.1 sec. average
Temperature:
1.Operating -40°~ 85°C
2.Storage -40°~ 85°C
3.Humidity Up to 95% non-condensing

Protocol:
1.GPS Protocol Default: NMEA 0183 (Secondary: SiRF binary)
2.GPS Output Data
3.SiRF binary >> position, velocity, altitude, status and control
4.Supports NMEA0183 V3.0 protocol, and supports command: GGA, GSA, GSV, RMC.
5.GPS transfer rate Software command setting (Default : 4800,n,8,1 for NMEA )
Dynamic Condition:
1.Acceleration Limit Less than 4g
2.Altitude Limit 18,000 meters (60,000 feet) max.
3.Velocity Limit 515 meters/sec. (1,000 knots) max.
4.Jerk Limit 20 m/sec*3
Low Noise Amp:
1.Amplifier Gain w/out cable 27 dB Typical
2.Filtering -25dB (+100 MHz)
3.Output VSWR 2.0 Max.
4.Voltage DC 3 ~ 5.0V
5.Current 15mA max @ 5VDC





Other Specifications

Chipset

SiRF STAR IV

Receiver

L1, C/A code

Position Accuracy Non DGPS

(Differential GPS

5-25 meter CEP without SA

horizontal position Accuracy

< 2.2 meters, WAAS / EGNOS 95% after revision

vertical position Accuracy

< 5 meters, WAAS / EGNOS 95% after revision

Max update rate

1 HZ

Time

1 microsecond synchronized GPS time

Position

1 to 5 meters

Velocity

515 meters (700 knots) / second

Support

EGNOS/WAAS/Beacon

Altitude

18,000 meters (60,000 feet ) max

Velocity

515 meters (700 knots) / second

Acceleration

4 G, max

Jerk

20 meters/second, max

Antenna Type

Built in Patch Antenna

Minimum signal tracked

-159dBm

NMEA output protocol

NMEA 0183 V.3.0

Baud rate

default 4800 bps

Data bit

8

Parity bit

1

Stop bit

1

Datum:

Datum WGS-84

Power

1.Voltage 5V ±5%
2.Current 60mA typical

Color

Black

Compatible

Win 7/Vista/XP,98,Linux,Mac

Dimension & weight:

72x25x14mm / 63.50g

Box & weight:

195x135x33mm / 103.00g

USB Cable Length

60" (152 cm)



Model picture



                                              SiRF Star IV High Accuracy RJ45 GPS Receiver GM1-86S4

SiRF Star IV High Accuracy RJ45 GPS Receiver GM1-86S4SiRF Star IV High Accuracy RJ45 GPS Receiver GM1-86S4SiRF Star IV High Accuracy RJ45 GPS Receiver GM1-86S4

SiRF Star IV High Accuracy RJ45 GPS Receiver GM1-86S4SiRF Star IV High Accuracy RJ45 GPS Receiver GM1-86S4









What’s in box



Mini USB Dongle(1 unit);CD-ROM (1 unit);Manual(1 unit)
