Most Popular Gps Beacon Receiver With SiRF III Chipset XC-GD75

Name: Most Popular Gps Beacon Receiver With SiRF III Chipset XC-GD75
Brand: xucai
SKU: 106650285
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

xucai

Model Number:

XC-GD75, XC-GD75-8-3

Player Type:

Other, Gps Receiver

Shenzhen Xucai Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Brand Name xucai

Model Number XC-GD75, XC-GD75-8-3

Player Type Other, Gps Receiver

Special Feature Mini System

Place of Origin Guangdong, China

Specifications

Most popular gps beacon receiver with SiRF III Chipset XC-GD75
1.SiRF III Chipset
2.High sensitivity & accuracy
3.USB Port

Most popular gps beacon receiver with SiRF III Chipset XC-GD75

Portable USB GPS receiver with low price XC-GD75
1.SiRF III Chipset
2.High sensitivity & accuracy
3.USB Port(Portable)

Specification
Some Parameters
1. Tracks up to 20 satellites. 2. 2 channel engine for high performance acquisition 3. 16 channel engine for high performance tracking 4. Equivalent to 4,000k/sec time-frequency windows with hybrid search engine 5. WAAS / EGNOS Support 6. Tracking sensitivity up to -159 dBm Acquisition Sensitivity up to -145 dBm Re-acquisition sensitivity up to -155dBm 7. Acquisition time (average) Cold Start< 33 seconds, Warm Start< 29 seconds, Hot Start< 2 seconds, 8. Environmental Characteristics Operation temperature: -10 ~ +70. Storage temperature: -40 ~85
Other Specifications
Chipset	SiRF III
Frequency	L1, 1575.42 MHz
Interface	USB connector
Data bit	8
Parity bit	1
Stop bit	1
Baud Rate	default 4800 bps
Color	Blue
Compatible	Win 7/Vista/XP,98,Linux,Mac,Andriod
Dimension & weight:	72x25x9mm / 23.00g
Box & weight:	130x105x23mm / 97.50g
