560RSS Digital Twin Rockwell Hardness Tester

Name: 560RSS Digital Twin Rockwell Hardness Tester
Brand: SCTMC
SKU: 106647091
Availability: InStock

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

SCTMC

Model Number:

560RSS

Shanghai Houstec Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name SCTMC

Model Number 560RSS

u 560RSS Instrument Description:

560RSS is a effective and affordable hardness testing machine with novel appearance and unique inside structure, features high measuring accuracy, reliable performance and applicable to wide fields, it is applicable to measure hardness testing of both Rockwell and Superficial Rockwell.
It can measure the hardness of hard metals, carburizing steels, quenching steels, hard cast irons, mild steels, A1, Cu and malleable irons.
560RSS has big LCD screen to display the measuring data, and it has the hardness conversion between Rockwell, Brinell, and Vickers, and it has other functions, such as, dwell time adjustment, data dispose, storage, printing and RS-232 output, etc.

u 560RSS Technical Specifications:

Product Name	Digital Superficial Twin Rockwell Hardness Tester
Model	560RSS
Rockwell Scales	HRA,HRB,HRC,HR15N,HR30N, HR45N,HR15T,HR30T,HR45T
Preliminary Test Force	3Kgf(29.4N), 10kgf(98.7N)
For Superficial Rockwell Testing	15Kgf(147.1N),30Kgf(294.2N),45Kgf(441.3N)
Dwell Time	Adjustable 1-60s
Hardness Indication	Digital LCD Display
Resolution	0.1HR
Loading Control	Automatic
Data Output	RS 232/Printer
Auto Hardness Conversion	HRC,HRB,HRA,HV,HK,HBW,etc
Max. Height Of Specimen	180mm
Instrument Throat	160mm
Dimension(LxWxH)	520 x215 x700mm
Packing Dimension	630 x440 x960mm
Gross/Net Weight	120Kg/90Kg
Execution Standard	GB/T230.2, JJG112, EN-ISO 6508 , ASTME-18
