HRS-150L Higher Digital Rockwell Hardness Tester

Name: HRS-150L Higher Digital Rockwell Hardness Tester
Brand: SCTMC
SKU: 106647085
Availability: InStock

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

SCTMC

Model Number:

HRS-150L

Shanghai Houstec Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name SCTMC

Model Number HRS-150L

u HRS-150L Instrument Description:

HRS-150L is a half automatic and intelligent hardness testing machine, except to lift up the anvil to touch the specimen and select the test force: 60Kgf(588.4N), 100Kgf(980.7N) and 150Kgf(1471N) in hand-knob manually, the other operations are entirely automatic.
The testing force, the process of loading, dwell and unloading, the hardness testing value, and the corresponding converted scale are displayed on LCD screen automatically.
HRS-150L system will remind the operator to select the corresponding testing force and indenter after scales choosing, and the automatic hardness testing and digital 0.1HR resolution display avoids the man-made error and enhance the measuring accuracy.
HRS-150L force knob adopts the metal material to replace the plastic material, it improves the instrument using-life greatly.
HRS-150L can make the hardness conversion among 14 hardness scales: HRA, HRB,HRC, HRD, HRF,HV, HK, HBW, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, it doesn’t need the operator to trace and check the fussy hardness comparison table again.
HRS-150L saves, displays and analyzes the value of maximum, minimum, average and tolerance automatically, the mini-printer prints the main measuring data automatically, and it supports PC communication in RS232 interface and cable.

u HRS-150L Technical Specifications:

Product Name	Digital Rockwell Hardness Tester
Model	HRS-150L
Rockwell Scales	HRA,HRB,HRC,HRD,HRE,HRF,HRG,HRH,HRk,HRL,HRM,HRR
Preliminary Test Force	10Kgf(98.07N)
Test Force	60Kgf(558.4N),100Kgf(980.7N),150Kgf(1471N)
Dwell Time	Adjustable 1-60s
Hardness Indication	digital LCD Display
Resolution	0.1HR
Loading Control	Automatic
Data Output	RS 232/Printer
Auto Hardness Conversion	HB, HK, HV, etc
Max. Height Of Specimen	350mm
Instrument Throat	165mm
Dimension(LxWxH)	520×220×900mm
Packing Dimension	630 x440 x1160mm
Gross/Net Weight	130Kg/110Kg
Execution Standard	GB/T230.2, JJG112, EN-ISO 6508 , ASTME-18

u HRS-150LStandard Packing List:

u HRS-150L Optional Accessories:
