Quadruplex Strain Controlled Direct Shear Apparatus
Model: LHZJ-4
Description:
Quadruplex Strain Controlled Direct Shear Apparatus is a kind of strain controlled direct shear apparatus used to test resisting shear strength of soil specimen, it usually adopts four specimens under the different vertical pressure and to exert horizontal force to the specimens so as to obtain shearing stress while the specimen is destroyed. According to Coulomb's law to confirm the resisting shear strength coefficient, angle of internal friction and coagulable force of the soil
Feature:
1.A new developed electric shearing apparatus by our factory.
2.Characteristic such as compact structure, large stage head of gearing shift, more gears, and strong commonality.
3.Instrument has the devices of slow speed shearing, reversing shearing, vertical loading.
4.Structure design is novel and practical, fixed with the rising and falling leveling structure.
5.Designed according to the new standard of GB123-88 Geotechnique Testing Method Standard.
6.Have the characteristics of strong electric shearing force, even transmission, low noise, light vibration, flexible and convenient operating, good shearing performance, and so on.
Main technical date:
1. Max. vertical load: 400Kpa
2. Power source: 220V 50HZ
3. Pressure classification: 100,200,300,400(Kpa)
4. Lever proportion: 1:12
5. Max. horizontal load: 1.2KN
6. Shearing box:4pcs
7. Specimen area: 30cm², height: 2cm
8. Thrust shaft pushing speed(mm/min): 2.4, 0.8, 0.1, 0.02mm/min
9. Dimension: 680 x 740 x 1050mm(L x W x H)
10.Weight: 200Kg
