Specifications
Geomembrane Hot Wedge Welder1. Power: 600W
2. Welding speed: 0-4m/min
3. Welding material thickness: 0.3-2mm
Geomembrane Hot Wedge Welder
LHPW-810 Geo-membrane Wedge Welder (Climbing Welder)
Function:
The STJIT series geo-membrane welding apparatus are a new style welding apparatus, developed by us ,has satisfied welding of the different thickness geo-membrane welding used in the hot fusibility material welding like PE, PVC, HDPE, EVA, PP .
Feature:
The series of welding machine use automatic continuous temperature PID control in temperature control; control of high precision, small temperature fluctuation.
Speed control adopt pulse width modulation(PWM)automatic regulator-speed and voltage circle;
DC servo motor drive, the bigger output torque, run smoothly. The machine can keeping speed invariableness at the time of climbing slope, vertical climbing and overload pavement change;
the series of welding machine working with steady performance, not be affected by outside temperature and voltage change.
The machine has excellent performance , easy to operate ,high-speed welding and excellent welding quality. Apply mainly to welding the high-thick materials such as dump.
Technical parameters
Input voltage:220V Frequency:50Hz
Power: 600W
Welding speed: 0-4m/min
Heating temperature: 0-450°C
Welding material thickness: 0.3-2mm
Weld width: 12.5mm×2 Middle cavity12mm
Weld Width: 15cm
Weld strength: ≥85% Base plate (Tensile shear direction)
Joint width: 150mm
Insulation class: Class II
Net Weight(about ): 5.5Kg
