Core Cutting Machine

Specifications

Simple cutting machine
- It is suitable for various specimen,such as concrete, asphalt, stone,etc.

Core Cutting Machine  (HQP-150)



Application:
The cutting machine is suitable for various specimen with different sizes in lab of asphalt, Concrete, and stone material,as a new cutting equipments , with some features like small size, easy to transportation and so on , Mainly used in central labs in construction projects, highway , communications and so on.The model is supplied complete with bearing parts with high precision sealing fabrication, also matched with diamond blades.
Specifications:
Size of cutting specimen: Dia50, 70,100,150mm
Max length of cutting specimen: 400mm
Rating speed of main shaft : 2300r/min
Rated power : 3KW
Voltage: 380V or 220V
Dia of saw blade: dia. 400mm
Net Dimension : 900×450 ×830mm
Net Weight : 95kg
