Specifications
Asphalt Penetration Apparatus1.COMPLIES TO ASTM D5
2. Automatic
3. ASTM D5
Automatic Asphalt Penetration Apparatus Model: SLH -2801I
Summary
1.The instrument is designed and made as per the standards GB/T4509 "Test Method for Penetration of Bitumen", T0604 "Bitumen Penetration Test" in the standard JTJ052-2000 Specifications and Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering and ASTM D5.
2.The instrument is suitable to determine the penetration of highway bitumen, modified asphalt, as well as liquid petroleum asphalt or residue of emulsified asphalt after evaporation.
3.The penetration of bituminous materials is expressed as the distance that a 100 g±0.05 g standard needle vertically penetrates into the sample without measurable fraction in 5 s at a constant temperature bath of 25±0.1 °C. It is used for evaluating the consistency of asphalt. The larger the penetration is; the thinner and softer the asphalt is.
4.The instrument can also be used for inspecting industry materials such as solid granule, powder, colloid, as well as food materials such as cream, glycine, etc. It has been widely used in the field of food industry, highway and traffic departments and other departments.
Main technical specifications
1.Measurement range: 0 penetration~600 penetrations;
2.Resolution: 0.1 penetration;
3.Timing range: 0s~60 s, and the error is less than ±0.1 s.
4.Heating power: 200 W;
5.Temperature controlling accuracy: 25±0.1 degrees Celsius (Note: the ambient temperature should not be higher than 20 degrees Celsius);
6.Data saved: 30 groups;
7.Constant temperature bath: harden glass container;
8.Stirrer: a magnetic stirrer;
9.Standard needle: 2.5±0.05 g and it conforms to the requirements of GB/T4509 and T0604.
10.Shifting holder: It has two ways to adjust the height of standard needle, so it is convenient to let the needle tip just touch the sample surface.
11.Power supply: AC 220 V±10%, 50 Hz.
Asphalt Penetration Apparatus / Bitumen Needle Penetration Test Device / Asphalt Penetrometer / Asphalt Tester / Bitumen Test Appratus / Asphalt Tester
SLH-2801C penetrometer
SLH-2801E Asphalt/ Bitumen penetrometer
SLH-2801E1 Asphalt/ Bitumen penetrometer
SLH-2801F Low-Temperature Asphalt/ Bitumen penetrometer
SLH-2801I Automatic Asphalt/ Bitumen penetrometer
SLH-2801G Penetrometer (for paraffin xax)
